JVC 32" - Rear Panel Layout and Connections

V32/37GCGI-UD1_V32/37GCJI-UD2 2006/8/3 下午 04:23
10
Rear View
AC Power Input
The LCD-TV is designed for AC use only and should be used with supplied AC Power cord. And,
connect AC plug into the wall outlet.
Main Power Switch
Before operating the LCD-TV or remote control, users must press MAIN POWER SWITH to
ON. The MAIN POWER SWITCH is located at the upper-left side of the LCD-TV.
A
C Power
Input
Main Power
Switch
