JVC 32" - Interface Ports Overview

V32/37GCGI-UD1_V32/37GCJI-UD2 2006/8/3 下午 04:23
11
Interface
○
1
Service Port : Ethernet RJ-45
○
2
Digital Audio Out : S/P DIF
○
3
Antenna: NTSC/ATSC/QAM Clear
○
4
Y Pb Pr 1 -- Audio (Left / Right)
○
5
Y Pb Pr 2 -- Audio (Left / Right)
○
6
S-Video 1 / AV 1 -- Audio (Left / Right)
○
7
S-Video 2 / AV 2 -- Audio (Left / Right)
○
8
Composite (AV/TV) Out
○
9
Subwoofer Out
○
10
Audio Out (Left / Right)
○
11
Service Port: RS-232
* ○
1
and ○
11
are only for updating software, please don’t open the cover.
○
5 CV 2
○
7 SV 2 / AV2
○
10
○
11
○
1
○
2
○
3
○
4 CV 1
○
6 SV1 / AV1
○
8
○
9
HDMI
DVI AUDIO
INPUT
D-SUB (VGA)
PC AUDIO
INPUT
