JVC GR-DVF10U User Manual

EN17
Journalistic Shooting
In some situations different angles of shooting may be
required for more dramatic results.
1
OPEN LCD MONITOR
Make sure the LCD monitor is fully open.
2
TILT LCD MONITOR
Tilt the LCD monitor in the most convenient
direction.
•The LCD monitor can rotate almost full circle (270°:
90° downward, 180° upward).
Brightness Control
You can adjust the brightness of the LCD monitor by
turning the Bright Dial.
1
ADJUST BRIGHTNESS
If you want to brighten the image . . .
Turn the Dial towards “+”.
If you want to darken the image . . .
Turn the Dial towards “–”.
Interface Shooting
A person you shoot can view himself/herself in the LCD
monitor, and you can even shoot yourself while viewing
your own image in the LCD monitor.
1
TILT LCD MONITOR UPWARD
Open the LCD monitor and tilt it upward to 180
degrees so that it faces forward.
•The monitor image is inverted vertically, and the
viewfinder also switches on.
2
START RECORDING
Point the lens towards the subject (yourself when self-
recording) and start recording.
•During Interface Shooting, the monitor image and
indications do not appear inverted as they would
when viewing a mirror.
NOTE:
The monitored image can be viewed on the LCD monitor
and in the viewfinder.
Bright Dial
Self-recording

JVC GR-DVF10U Specifications

General

Optical Zoom	10x
Digital Zoom	700x
Image Sensor Size	1/4 inch
Video Resolution	720 x 480
LCD Screen Size	2.5 inch
Optical Sensor Size	1/4 inch
Image Stabilizer	Electronic
White Balance	Auto, Manual
Microphone Operation Mode	Stereo
Display Type	LCD
Sensor	CCD
Recording Media	MiniDV Tape
Video Recording Format	DV
Weight (without battery and tape)	0.9 lbs
Type	MiniDV
Focus Adjustment	Automatic, manual
Shooting Modes	Auto, Manual
White Balance Presets	Daylight
Connector Type	USB, FireWire
Microphone	Microphone - built-in - stereo
Viewfinder	Color
Interface	IEEE 1394, USB
Effective Pixels	680, 000
