EN71
SPECIFICATIONS
Camcorder
General
Power supply : DC 6.0 V
Power consumption
LCD monitor off, viewfinder on : Approx. 5.5 W
LCD monitor on, viewfinder off : Approx. 6.0 W
LCD monitor on, viewfinder on : Approx. 6.6 W
Video light : Approx. 3 W
Format : DV Format (SD mode)
Signal format : PAL Standard
Video signal recording format : Digital Component Recording
Cassette : Mini DV Cassette
Tape Speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 60 min.
LP: 90 min. (using M-DV60ME cassette)
Pickup : 1/4" CCD
Lens : F1.6, f = 3.9 to 62.4 mm, 16:1 Power Zoom Lens
Filter diameter : ø40.5 mm
LCD monitor : 2.5" diagonally measured, LCD panel/TFT active matrix system
Viewfinder : Electronic viewfinder with 0.55" colour LCD
Speaker : Monaural
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Dimensions : 99 (W) x 119 (H) x 198 (D) mm
(with the LCD monitor closed and with the viewfinder fully tilted
downward)
Weight : Approx. 800 g
Connectors
S-Video : Y: 1Vp-p, 75 Ω, analogue output
C: 0.29 Vp-p, 75 Ω, analogue output
JLIP : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
Video : 1 Vp-p, 75 Ω unbalanced, analogue output
(via Video output connector)
Audio : –8 dBs, 1 kΩ analogue output (via Audio output connector)
External microphone input : –68 dBs, high impedance unbalanced with ø3.5 mm (stereo)
AC Power Adapter/Charger AA-V15EK
Power requirement : AC 110 V to 240 V`, 50/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V
, 1.8 A
Charging system : Constant current, peak detection, timer controlled
Dimensions : 140 (W) x 42 (H) x 68 (D) mm
Weight : Approx. 350 g
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change
without notice.
