Adjusting the Digital Video Cassette Camera with JVC Service Support System Software
99
Sensor (1)
Bit Description High Low
7 End Sensor End Normal
6 Start Sensor Start Normal
5 REC Safety Record Disabled Record Enabled
4 Dew Sensor Dew Normal
3 Tape Existence Loaded Not Loaded
2 Dust Sensor Dusty Normal
1 Tape Type MP ME
0 PB Tape Speed LP SP
Table 27 Data Dump - Sensor (1)
Sensor (2)
Bit Description High Low
7 ITT Detected Not Detected
6 Mode Shift Shifting Shift Ends
5 Cleaning Tape Cleaning Tape Cleaning Tape
4 In Recording Recording from next Frame Recording to the 2nd Frame
3 0 Point In Detection Normal
2 1394 Cable Detected Not Detected
1 Tape Detected Not Detected
0 1394 Signal Detected Not Detected
Table 28 Data Dump - Sensor (2)
Sensor (3)
Bit Description High Low
7 AGCMS Copy Inhibit Not Detected
2 Emergency Mode Off On
1 PB Encoding Mode 11: 32 kHz 12 Bit 00: 48 kHz
0 PB Encoding Mode 10: 32 kHz 16 Bit 01: 44.1 kHz
Table 29 Data Dump - Sensor (3)
Sensor (4)
Bit Description High Low
7 VCGMS Copy Inhibit Not Detected
1 PB Squeeze Squeeze Record Detected Not Detected
0 PB Cinema Cinema Record Detected Not Detected
Table 30 Data Dump - Sensor (4)
