Adjusting the Digital Video Cassette Camera with JVC Service Support System Software
101
Other Information (1)
Bit Description High Low
7 Animation Being Executed Yes No
6 After-Recording Being Executed Yes No
5 Insertion Being Executed Yes No
4 Soft-Stop Being Executed Yes No
3 Servo Finish Allowed Yes No
2 Write Enable Tape Yes No
1 Voltage Attenuation Yes No
0 Rehearsal Yes No
Table 36 Data Dump - Other Information (1)
Other Information (2)
Bit Description High Low
7 Tape End Yes No
6 Tape Start Yes No
5 Tape Loaded Yes No
4 Ltl Detection Detected Not Detected
3 Emergency Yes(Occur) No
2 Dew Yes(Occur) No
1 Housing Closed Open
0 Interval Yes No
Table 37 Data Dump - Other Information (2)
System Mode
Data Description
0x04 VTR Mode
0x02 Power Off Mode
0x01 Camera Mode
Table 38 Data Dump - System Mode
