Adjusting the Digital Video Cassette Camera with JVC Service Support System Software
93
Electronic Zoom Operation
Bit Definition High Low
3 Electronic Zoom Power Control Active Passive
2 In Electronic Zoom Operation Moving Stopped
1 Electronic Zoom Operation Direction Telephoto Wide
Table 10 Data Dump - Electronic Zoom Operation
Focus Control
Bit Description High Low
7 Zoom Initialize No Yes
6 Focus Initialize No Yes
5 Focus/Zoom Pulse Error Control Not Check Check
4 AF System Control Disable Enable
2 Zoom Limiter Control Limiter Disable Limiter Enable
1 Focus Limiter Control Limiter Disable Limiter Enable
0 Focus Mode Auto Focus Manual Focus
Table 11 Data Dump - Focus Control
Iris Control
Bit Description High Low
7 Shutter Control Manual Auto
6 Sport Mode Control On Off
5 Portrait Mode Control On Off
4 Manual Shutter Control On Off
3 Iris Control Manual Auto
2 User Iris Control Manual Auto
1 AGC Control AGC Manual AGC Auto
0 Manual AGC Control AGC On AGC Off
Table 12 Data Dump - Iris Control
White Balance Control
Bit Description High Low
7 Initialize Mode Warm Boot Cold Boot
3 Open Loop Control Loop Control Request Normal Action
2 White Balance Sensor Can’t Use Can Use
1 White Balance Manual Mode Lock Preset Mode
0 White Balance Control Manual (User Control) Auto
Table 13 Data Dump - White Balance
Camera Shake Detection
Bit description High Low
0 EIS Disable Flag Disabled Enabled
Table 14 Data Dump - Camera Shake Detection
