110 EN
AC Power Adapter/Charger AA-V50EK
Power requirement : AC 110 V to 240 V`, 50/60 Hz
Power consumption : 20 W
Output
Charge : DC 7.2 V , 0.63 A
VTR : DC 6.3 V , 1.8 A
Dimensions : 122 (W) x 39 (H) x 92 (D) mm
Weight : Approx. 380 g
Docking Station CU-V501E
For General
Dimensions : 115 mm (W) x 31 mm (H) x 55 mm (D)
Weight : Approx. 90 g
For Connectors
S-Video : Y: 1Vp-p, 75 Ω, analogue output
C: 0.29 Vp-p, 75 Ω, analogue output
Video : 1Vp-p, 75 Ω, analogue output
Audio : –8 dBs, 1 kΩ, analogue output
JLIP : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
Editing : ø3.5 mm, 2-pole
PC : ø2.5 mm, 3-pole
External microphone input : –68 dBs, high impedance unbalanced with ø3.5 mm (stereo)
E & O.E. Design and specifications subject to change without notice.
SPECIFICATIONS
(cont.)
