Specifications
General
Item Description
Power DC 12 V
Power
consumption
Approx. 10.2 W
(during recording with backlight
set to [STANDARD] while the
viewfinder is in use)
Mass Approx. 2.4 kg (with battery)
Allowable
operating
temperature
0 °C to 40 °C (32 °F to 104 °F)
Allowable
operating
humidity
30 %RH to 80 %RH
Allowable
storage
temperature
-20 °C to 50 °C (-4 °F to 122 °F)
Terminal Section
Item Description
[HD/SD SDI] output terminal (480i or 576i:
Downconverted 720p/1080i: embedded audio),
BNC (unbalanced)
HD-SDI Compliant with SMPTE 292 M
SD-SDI Compliant with SMPTE 259 M
[INPUT1/INPUT2] terminal
[MIC] -50 dBu, 3 kK, XLR (balanced),
+48 V output (phantom power
supply)
[LINE] +4 dBu, 10 kK, XLR (balanced)
[AUX] terminal -22dBu, 10 kK, 3.5 mm stereo
mini jack (unbalanced)
[AV] terminal 4-pin 3.5 mm mini jack
Video signal 1.0 V (p-p)
Audio signal -8 dBu (during reference level
input), 1 kK (unbalanced)
[x] terminal 3.5 mm mini jack (stereo)
[REMOTE]
terminal
2.5 mm wired remote control
[U] terminal
[DEVICE] Mini USB-B type, USB 2.0,
miniB, slave function (mass
storage class) only
[TC] terminal
[IN] 1.0 V(p-p) to 4.0 V(p-p) high
impedance
[OUT] 2.0 ± 1.0 V(p-p) low impedance
Lens Section
Item Description
Lens Fujinon F1.6, 23x, f=4.1 mm to
94.3 mm
(35 mm conversion: 29 mm to
667 mm)
Filter diameter Φ72 mm
Camera Section
Item Description
Image pickup
device
1/3-inch Progressive CMOS
Color separation
prism
F1.6, 3-color separation prism
Sync system Internal sync (built-in SSG)
Optical filter OFF, 1/4, 1/16, 1/64
Gain -6dB, -3dB, 0dB, 3dB, 6dB,
9dB, 12dB, 15dB, 18dB, 21dB,
24dB,
Lolux (30dB, 36dB), ALC
Electronic
shutter
1/4 to 1/10000, EEI
Variable Frame
Rate
2/30-60/30fps, 2/25-50/25fps,
2/24-60/24fps
LCD monitor 3.5-inch LCD, 16:9 920K pixels
Viewfinder 0.45-inch LCOS, 1.22M pixels
(852 x 480 x 3)
Storage Section
Item Description
Supported
media
SDHC/SDXC
Slots x 2
140
