Connecting To A Dolby Digital Decoder or An Amplifier
With A Built-in DTS (DVD deck only)
These instructions enable you to connect your unit to a
Dolby Digital Decoder or an amplifier with built-in DTS.
Make connections.
Connect the optical cable between the unit and the
Dolby Digital Decoder or amplifier with a built-in DTS.
NOTES:
● For Dolby Digital sound, set “DIGITAL AUDIO OUTPUT” to
“DOLBY DIGITAL/PCM”. (
墌 pg. 68)
● For DTS sound, set “DIGITAL AUDIO OUTPUT” to “STREAM/
PCM”. (
墌 pg. 68)
CAUTIONS:
● This unit has a dynamic range of more than 80 dB with regards
to its Hi-Fi audio capability. It is recommended that you check
the maximum level if you are going to listen to the Hi-Fi audio
signals through a stereo amplifier. A sudden surge in the input
level to the speakers may damage them.
● Some speakers and televisions are specially shielded to
prevent television interference. If both are of the non-shielded
type, do not place the speakers adjacent to the TV set as this
can adversely affect the video playback picture.
Note for connection:
Remove the connector cover from
the unit and remove the protection
cap from the cable.
Optical cable
(not provided)
Dolby Digital Decoder or
amplifier with built-in DTS
DIGITAL
AUDIO OUT
To DIGITAL AUDIO
input
XVS30EK_01.book Page 63 Tuesday, September 2, 2003 5:01 PM
To Next Page
