KD-LH3150, KD-LH3100
1-52 (No.49838)
36 Po4 O General output port-4
A7 O Address-7 for external DRAM
37 Po5 O General output port-5 (Address output-7 for external SRAM)
A8 O Address-8 for external DRAM
38 Po6 O General output port-6 (Address output-6 for external SRAM)
A9 O Address-9 for external DRAM
39 Po7 O General output port-7
40 VSS - Ground for digital circuit
41 IRQ/REQ I/O Interruption input (BS I/F:REQ output)
A11R O Address-11 for external DRAM
42 VDDM - Power supply for built-in 1Mbit SRAM (2.5V)
43 Fi0 I Flag input-0
/OE O Enable output for external up DRAM
44 Fi1 I Flag input-1
/CAS O Column address strobe for external DRAM
45 VSSM - Ground for built-in 1Mbit SRAM
46 Pi0 I General input-0
io0 I/O Data I/O-0 for external DRAM
47 Pi1 I General input-1
io1 I/O Data I/O-1 for external DRAM
48 VSS - Digital ground
49 Pi2 I General input-2
io2 I/O Data I/O-2 for external DRAM
50 Pi3 I General input-3
io3 I/O Data I/O-3 for external DRAM
51 Pi4 I General input-4
io4/CLCK I/O Data I/O-4 for external DRAM
52 VDD - Power supply for digital circuit (2.5V)
53 Pi5 I General input-5
io5/DATA I/O Data I/O-5 for external DRAM / SUBQ I/F data input
54 TSTiN I Test terminal (H or L fixed)
io6/SFSY I/O Data I/O-6 for external DRAM / SUBQ I/F frame sync input
55 Fi2 I Flag input-2
io7/SBSY I/O Data I/O-7 for external DRAM / SUBQ I/F block sync input
56 VSSP - Ground for VCO circuit
57 Pdo O PLL phase detector signal output
58 Vcoi I VCO control voltage input
59 VDDP - Power supply for VCO circuit (2.5V)
60 CKi/CKo/Po6 I/O External system clock input/clock output/general output-6
CKo/Po6/SBOK I/O Clock output/general output-6/SUBQ I/F SBOK input
61 VDDX - Power supply for crystal oscillator (2.5V)
62 Xi I Crystal oscillator input
63 Xo O Crystal oscillator output
64 VSSX - Ground for crystal oscillator
Pin No. Symbol I/O Function
