KD-LH3150,KD-LH3100
3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 ---------------------- CD MECHA
2 GE10043-210A TOP CHASSIS
3 GE40135-001A EARTH PLATE
4 GE30938-003A HEAT SINK
5 GE30393-002A BOTTOM COVER
6 FSMA3005-001 INSULATOR
7 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
8 FSKZ4005-001 SCREW (x2)
9 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
10 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
11 QYSDST2610Z SCREW 2.6mm x 10mm
12 QYSDSF2006M SCREW 2mm x 6mm(x2)
13 QYSDST2004Z SCREW 2mm x 4mm(x5)
14 GE30823-002A F. CHASSIS ASSY
15 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
16 FSYH4036-046 SHEET
17 GE30827-001A OPEN LEVER
18 GE30824-002A LOCK LEVER(O.L)
19 GE30826-001A RELEASE LEVER
20 GE30829-001A LOCK LEVER(TOP)
21 GE30825-001A LOCK LEVER(L)
22 GE30828-001A LOCK LEVER(R)
23 GE40154-001A GEAR
24 QZW0108-002 OIL DAMPER
25 FSKW4012-002 T.SPRING
26 VKW5264-005 T.SPRING
27 GE40155-001A T.SPRING
28 QYSDSF2006M SCREW 2mm x 6mm
29 VKW5263-002 T.SPRING
30 GE40157-001A T.SPRING
31 GE40153-001A T.SPRING
32 GE40156-001A BLIND
33 GE10061-003A FRONT PANEL
LH310
0J
33 GE10061-004A FRONT PANEL
LH315
0C,LH
3150J
34 GE30917-002A FINDER ASSY
LH310
0J
34 GE30917-009A FINDER ASSY
LH315
0C
34 GE30917-001A FINDER ASSY
LH315
0J
35 GE30832-001A POWER BUTTON
36 GE30856-001A KNOB
37 GE30859-001A SEL BUTTON
38 GE30834-001A RIM LENS
39 GE30836-001A RIM COVER(L)
40 GE20152-001A PRESET BUTTON
41 GE30838-004A CD BTN
42 GE30934-001A DETACH BUTTON
43 GE30999-001A COMP.SPRING
44 GE30835-001A NAVIGATION BTN
45 FSYH4036-013 SHEET
46 GE30937-002A NAVI BASE
47 GE30858-001A RIM COVER(R)
48 GE30860-001A FM/AM BTN
49 GE30861-002A EQ BTN
50 GE30914-002A EJECT BUTTON
51 VKW3001-330 COMP.SPRING
52 GE10062-003A REAR COVER
53 VKZ4777-001 MINI SCREW (x5)
54 GE40158-001A SIDE LENS (x2)
55 GE40174-001A INSULATOR
56 GE30837-001A LCD CASE
57 LV42850-002A L.C.D.LENS
58 LV33404-001A LIGHT CASE
59 LV42884-001A LENS FILTER
60 LV42995-001A LENS FILTER
61 LV42955-002A LENS SHEET
62 LV43084-001A DOUBLE FACE
63 LV40848-034A SPACER
64 LV40846-036A SPACER
65 GE30777-001A NAME PLATE
LH310
0J
65 GE30783-001A NAME PLATE
LH315
0C,LH
3150J
66 GE30857-001A LED HOLDER (x2)
67 QLD0232-001 LCD MODULE
68 VYSH101-009 SPACER
69 QAM0419-001 CAR PLUG CORD
70 QAM0447-001 L-INCABLE
LH315
0C,LH
3150J
71 VYTA500-001 PIN CAP (x2)
LH310
0J
71 VYTA500-001 PIN CAP (x4)
LH315
0C,LH
3150J
72 LV42894-001A BRIGHT SHEET
73 QUQ105-2207AE FFC WIRE
74 QMFZ047-150-T FUSE 15A
75 GE30912-006A REAR BRACKET
76 QYSDST2606Z SCREW 2.6mm x 6mm
77 QYSDST2606Z SCREW 2.6mm x 6mm
78 QYSDST2606Z SCREW 2.6mm x 6mm
79 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
80 QYSDSF2606Z SCREW 2.6mm x 6mm
81 GE40172-002A IC BRACKET
82 GE40124-001A REG BRACKET
