KD-LH3150,KD-LH3100
3-9
Front board
Block No. [0][2][0][0]
R745 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R746 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R747 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R748 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R749 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R750 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R751 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R754 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R755 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R756 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R757 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R758 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R759 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R762 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R767 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R773 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R774 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R775 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R776 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R777 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R778 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R779 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R780 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R781 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R782 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R783 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R784 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R785 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R786 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R787 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R788 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R789 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R790 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R791 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R792 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R793 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R795 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R797 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R798 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R799 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R901 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R902 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R903 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R904 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R905 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R906 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R908 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R909 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R910 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R911 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R912 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R913 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R914 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R915 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R917 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R918 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R919 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R921 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R922 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R923 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R924 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R925 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R926 NRSA63D-473X MG RESISTOR 47k
Ω
1/16W D
R927 NRSA63D-472X MG RESISTOR 4.7k
Ω
1/16W D
R928 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R929 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R951 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R953 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R954 NRSA63J-4R7X MG RESISTOR 4.7
Ω
1/16W J
R955 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R961 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R962 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R963 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R981 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R982 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R984 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R985 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R986 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R987 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R989 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R990 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
LH315
0C,LH
3150J
R992 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R993 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R996 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R997 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R998 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R999 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L1 NQL114K-100X COIL 10uH K
L701 NQL114K-470X INDUCITOR 47uH K
L702 NQL114K-470X INDUCITOR 47uH K
L753 NQL114K-470X INDUCITOR 47uH K
L901 QQR1378-001 CHOKE COIL
L921 NQLZ007-151X COIL 150uH
L922 NQL114M-4R7X COIL 4.7uH M
BZ795 QAN0023-001Z BUZZER
CN131 QGA2006C1-04 CONNECTOR W-B (1-4)
CN141 QGA2006F1-04 CONNECTOR W-B (1-4)
LH315
0C,LH
3150J
CN601 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0611-001 16P CONNECTOR
CN902 QNZ0095-001 CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J121 QNN0490-001 PIN JACK
PP1 QZW0010-001 STYLE PIN
LH315
0C,LH
3150J
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSQ1A11-V06Z TACT SW I/M
TU1 QAU0204-002 TUNER
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC801 MN102H60KCG IC
IC802 LH28F160BJHET92 I.C (FLASH ROM)
IC803 IC-PST3424U-X IC
IC804 NJU7241F33-X IC
IC805 RPM6938-SV4 REMOCON RCV
Q401 UN2211-X TRANSISTOR
Q402 UN2211-X TRANSISTOR
Q403 UN2211-X TRANSISTOR
Q404 UN2211-X TRANSISTOR
Q405 UN2211-X TRANSISTOR
Q406 UN2211-X TRANSISTOR
Q407 UN2211-X TRANSISTOR
Q408 2SD601A/R/-X TRANSISTOR
Q409 2SD601A/R/-X TRANSISTOR
Q410 2SD601A/R/-X TRANSISTOR
Q411 2SD601A/R/-X TRANSISTOR
Q412 2SD601A/R/-X TRANSISTOR
Q413 2SD601A/R/-X TRANSISTOR
Q414 2SD601A/R/-X TRANSISTOR
Q415 2SD601A/R/-X TRANSISTOR
Q416 2SD601A/R/-X TRANSISTOR
Q417 2SD601A/R/-X TRANSISTOR
Q418 2SD601A/R/-X TRANSISTOR
Q419 2SD601A/R/-X TRANSISTOR
Q420 2SD601A/R/-X TRANSISTOR
Q421 2SD601A/R/-X TRANSISTOR
Q422 2SD601A/R/-X TRANSISTOR
Symbol No.
Part No. Part Name Description Local
