KD-LH3150,KD-LH3100
3-15
Packing and accessories
Block No. [M][3][M][M]

Symbol No.
Part No. Part Name Description Local
A 1 GET0147-001A INST BOOK ENG FRE SPA
A 2 LVT1042-002A IMAGE CONVERTER
A 3 GET0147-002B INSTALL MANUAL ENG FRE SPA
A 4 GET0165-001A DEMO MODE SHEET
A 5 GET0155-001A CAUTION SHEET
A 6 LVT0717-001B TROUBLE SHEET(C
A 7 LVT1046-001A MP3 SHEET
A 8 BT-51018-3 WARRANTY CARD
LH310
0J
A 8 BT-51029-1 WARRANTY CARD
LH315
0J
A 9 BT-52006-2 WARRANTY CARD
A 10 BT-51028-2 SVC CENTER LIST
LH310
0J,LH
3150J
A 12 VKZ4027-202 PLUG NUT
A 13 VKH4871-001SS MOUNT BOLT
A 14 VKZ4328-001 LOCK NUT
A 15 WNS5000Z WASHER
A 16 GE40130-001A HOOK (x2)
A 17 FSJB3002-00C HARD CASE
LH310
0J
A 17 FSJB3002-00C HARD CASE
LH315
0C,LH
3150J
A 18 GE20137-003A MOUNTING SLEEVE
LH315
0C,LH
3150J
A 18 GE20137-003A MOUNTING SLEEVE
LH310
0J
A 19 GE20150-001A TRIM PLATE ASSY
A 20 RM-RK50 REMOCON UNIT
A 21 ---------------------- BATTERY
A 22 QAM0306-001 16P CORD ASSY
KIT KSFX480K-SCREW1 SCREW PARTS KIT A12 to A16
P 1 FSPG4002-001 POLY BAG
P 2 FSPG4002-001 POLY BAG
P 3 QPA00801205 POLY BAG 8cm x 12cm
P 4 FSYH4036-068 SHEET
P 5 QPA01003003 POLY BAG 10cm x 30cm
P 6 QPC03004315P POLY BAG 30cm x 43cm
P 7 GE30778-001A CARTON
LH310
0J
P 7 GE30928-001A CARTON
LH315
0C
P 7 GE30784-001A CARTON
LH315
0J
P 8 GE10070-001A EPS CUSHION
