KD-LH3150,KD-LH3100
3-6
Electrical parts list
Main board
Block No. [0][1][0][0]

Symbol No.
Part No. Part Name Description Local
IC131 BU4066BCFV-X IC
IC132 NJM4565V-X IC
IC281 BA3220FV-X IC
LH315
0C,LH
3150J
IC301 BA3220FV-X IC
LH315
0C,LH
3150J
IC701 UPD784217AGC205 IC
IC702 IC-PST9333U-X IC
IC703 BR24L16F-W-X IC
IC781 HD74HC126FP-X IC
IC901 HA13164A IC
IC911 TDA7404D-X IC
IC912 M62449FP-X IC
IC921 NJM2360AM-X IC
IC951 LA47505 IC
Q1 2SB624/4/-X TRANSISTOR
Q2 UN2211-X TRANSISTOR
Q3 2SB624/4/-X TRANSISTOR
Q121 2SD1781K/QR/-X TRANSISTOR
Q122 2SD1781K/QR/-X TRANSISTOR
Q131 UN2211-X TRANSISTOR
Q132 UN2211-X TRANSISTOR
Q133 2SC2412K/RS/-X TRANSISTOR
Q191 2SD601A/R/-X TRANSISTOR
Q221 2SD1781K/QR/-X TRANSISTOR
Q222 2SD1781K/QR/-X TRANSISTOR
Q701 UN2213-X DIGI TRANSISTOR
Q702 UN2214-X TRANSISTOR
Q703 UN2211-X TRANSISTOR
Q750 UN2211-X TRANSISTOR
Q751 UN2211-X TRANSISTOR
Q752 UN2213-X DIGI TRANSISTOR
Q753 UN2211-X TRANSISTOR
Q754 UN2211-X TRANSISTOR
Q795 UN2211-X TRANSISTOR
Q901 UN2111-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
Q903 2SB709A/QR/-X TRANSISTOR
Q904 2SD601A/R/-X TRANSISTOR
Q941 UN2111-X TRANSISTOR
Q942 UN2111-X TRANSISTOR
Q951 UN2211-X TRANSISTOR
D1 1SS355-X SI DIODE
D2 1SS355-X SI DIODE
D3 MA152WK-X DIODE
D121 MA152WA-X DIODE
D131 MA152WK-X DIODE
D192 1SS355-X SI DIODE
D193 1SS355-X SI DIODE
D221 MA152WA-X DIODE
D701 1SS355-X SI DIODE
D702 1SS355-X SI DIODE
D703 1SS355-X SI DIODE
D704 1SS355-X SI DIODE
D711 UDZS6.2B-X Z DIODE
D712 UDZS6.2B-X Z DIODE
D713 UDZS6.2B-X Z DIODE
D714 UDZS6.2B-X Z DIODE
D715 UDZS6.2B-X Z DIODE
D716 UDZS6.2B-X Z DIODE
D717 SML-310LT/MN/-X LED
D718 SML-310LT/MN/-X LED
D719 SML-310LT/MN/-X LED
D720 UDZS6.2B-X Z DIODE
D901 1N5404-TU-15 DIODE
D904 RB160M-30-X SB DIODE
D905 RB160M-30-X SB DIODE
D921 RB160M-30-X SB DIODE
D941 UDZS11B-X Z DIODE
D942 1SS355-X SI DIODE
D951 1SS355-X SI DIODE
C1 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C2 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3 QERF1CM-476Z E CAPACITOR 47uF 16V M
C4 QERF1CM-476Z E CAPACITOR 47uF 16V M
C6 QERF1AM-107Z E CAPACITOR 100uF 10V M
C7 QERF1AM-107Z E CAPACITOR 100uF 10V M
C10 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C25 NCS31HJ-331X C CAPACITOR 330pF 50V J
C27 QERF1HM-104Z E CAPACITOR 0.1uF 50V M
C101 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C102 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C103 NCS31HJ-821X C CAPACITOR 820pF 50V J
C104 QERF1HM-105Z E CAPACITOR 1uF 50V M
C110 QERF1HM-105Z E CAPACITOR 1uF 50V M
C115 NFV81CM-105X TS E. CAPACITOR 1uF 16V M
C116 NFV81CM-105X TS E. CAPACITOR 1uF 16V M
C117 NCB31HK-331X C CAPACITOR 330pF 50V K
C118 NCB31HK-331X C CAPACITOR 330pF 50V K
C120 QERF1CM-476Z E CAPACITOR 47uF 16V M
C122 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C123 NCS31HJ-101X C CAPACITOR 100pF 50V J
C124 QERF1HM-105Z E CAPACITOR 1uF 50V M
C125 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C126 QERF1AM-107Z E CAPACITOR 100uF 10V M
C127 NCB31HK-472X C CAPACITOR 4700pF 50V K
C131 QERF1CM-106Z E CAPACITOR 10uF 16V M
C132 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C133 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C134 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C135 NCB31HK-562X C CAPACITOR 5600pF 50V K
C136 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C137 QERF1CM-476Z E CAPACITOR 47uF 16V M
C138 QERF1CM-106Z E CAPACITOR 10uF 16V M
C139 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C140 NCB31HK-682X C CAPACITOR 6800pF 50V K
C141 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C142 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C143 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C144 NCS31HJ-101X C CAPACITOR 100pF 50V J
C151 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
LH315
0C,LH
3150J
C152 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
LH315
0C,LH
3150J
C161 NCS31HJ-101X C CAPACITOR 100pF 50V J
LH315
0C,LH
3150J
C162 QERF1HM-105Z E CAPACITOR 1uF 50V M
LH315
0C,LH
3150J
C165 NCB31EK-473X C CAPACITOR 0.047uF 25V K
LH315
0C,LH
3150J
C166 QERF1HM-105Z E CAPACITOR 1uF 50V M
LH315
0C,LH
3150J
C181 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C191 QERF1HM-105Z E CAPACITOR 1uF 50V M
C192 QERF1CM-226Z E CAPACITOR 22uF 16V M
C193 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C194 QERF1HM-224Z E CAPACITOR 0.22uF 50V M
C201 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C202 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C203 NCS31HJ-821X C CAPACITOR 820pF 50V J
C204 QERF1HM-105Z E CAPACITOR 1uF 50V M
C210 QERF1HM-105Z E CAPACITOR 1uF 50V M
C215 NFV81CM-105X TS E. CAPACITOR 1uF 16V M
C216 NFV81CM-105X TS E. CAPACITOR 1uF 16V M
C217 NCB31HK-331X C CAPACITOR 330pF 50V K
C218 NCB31HK-331X C CAPACITOR 330pF 50V K

