KD-LH3150,KD-LH3100
3-11
Sub board
Block No. [0][3][0][0]
R475 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R476 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R477 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R478 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R479 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R801 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R803 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R804 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R806 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R807 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R808 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R809 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R810 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R811 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R812 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R813 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R814 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R815 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R816 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R817 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R818 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R819 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R820 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R821 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R822 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R823 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R824 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R825 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R826 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R827 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R828 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R829 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R830 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R831 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R832 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R833 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R834 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R835 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R836 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R837 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R838 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R839 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R841 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R842 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R843 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R844 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R845 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R846 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R847 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R848 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R849 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R850 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R851 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R852 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R853 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R854 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R855 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R856 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R857 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R858 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R859 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R860 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R861 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R862 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R863 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R864 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R865 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R866 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R867 NRSA63J-225X MG RESISTOR 2.2M
Ω
1/16W J
R868 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R869 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R870 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R871 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R872 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R873 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R874 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R877 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R878 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R879 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R880 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R881 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R882 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R883 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R884 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R885 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R886 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R887 NRSA63J-391X MG RESISTOR 390
Ω
1/16W J
R888 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R889 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R890 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R891 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R892 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R893 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R894 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R895 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R896 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R897 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R898 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R899 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L801 NQL114K-470X INDUCITOR 47uH K
CN801 NNZ0087-001 CAR CONNECTOR
CN802 QGF0523F1-40W CONNECTOR FFC/FPC (1-40)
EN801 QSW0976-001 ROTARY ENCODER
S802 NSW0066-001X TACT SW
S803 NSW0066-001X TACT SW
S804 NSW0066-001X TACT SW
S805 NSW0066-001X TACT SW
S806 NSW0066-001X TACT SW
S807 NSW0066-001X TACT SW
S808 NSW0066-001X TACT SW
S809 NSW0066-001X TACT SW
S810 NSW0066-001X TACT SW
S811 NSW0066-001X TACT SW
S812 NSW0066-001X TACT SW
S813 NSW0066-001X TACT SW
S814 NSW0066-001X TACT SW
S815 NSW0066-001X TACT SW
S816 NSW0066-001X TACT SW
S817 NSW0066-001X TACT SW
S818 NSW0066-001X TACT SW
TH801 NAD0022-103X N THERMISTOR 10k
Ω
10mW F
X801 NAX0586-001X RESONATOR 25.000MHz
Symbol No.
Part No. Part Name Description Local
IC501 TMP91CW12AF4R31 IC
IC503 HD74HCT126T-X IC
IC504 NJU7241F33-X IC
IC571 PCM1716E-X IC
IC572 NJM4565V-X IC
IC601 TA2157FN-X RF AMP IC
IC621 TC94A14FA CD LSI IC
IC651 NJU7241F25-X IC
IC652 TC94A20F-008 IC
IC681 BA5830FP-X IC
Q501 UN2111-X TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q571 UN2111-X TRANSISTOR
Q572 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D501 1SS355-X SI DIODE
D502 1SS355-X SI DIODE
D503 1SS355-X SI DIODE
D504 1SS355-X SI DIODE
