KD-LH3150, KD-LH3100
(No.49838)1-55
22 P94 I/O Serial receiving data 1
RX1 I Serial receiving data 1
23 P95 I/O Input/output port
SCLK1 I/O Serial clock input/output 1
CTS1 I Serial data transmitting possibility 1 (Clear to Send)
24 AM0 I Action mode 0
25 DVCC - Power supply
26 X2 - Crystal oscillator connecting terminal
27 DVSS - Ground
28 X1 - Crystal oscillator connecting terminal
29 AM1 I Action mode 1
30 RESET
I Reset input
31 P96 I/O Input/output port
XT1 I Low frequency generator connecting terminal
32 P97 I/O Input/output port
XT2 I Low frequency generator connecting terminal
33 EMU0 O Open
34 EMU1 O Open
35 PA0 I/O Input/output port
INT1 I Interrupt request 1
36 PA1 I/O Input/output port
INT2 I Interrupt request 2
37 PA2 I/O Input/output port
INT3 I Interrupt request 3
38 PA3 I/O Input/output port
INT4 I Interrupt request 4
39 PA4 I/O Input/output port
40 PA5 I/O Input/output port
41 PA6 I/O Input/output port
42 PA7 I/O Input/output port
43 ALE O Address latch enable
44 P00 I/O Input/output port
AD0 I/O Address data bus 0
45 P01 I/O Input/output port
AD1 I/O Address data bus 1
46 P02 I/O Input/output port
AD2 I/O Address data bus 2
47 P03 I/O Input/output port
AD3 I/O Address data bus 3
48 P04 I/O Input/output port
AD4 I/O Address data bus 4
49 P05 I/O Input/output port
AD5 I/O Address data bus 5
50 P06 I/O Input/output port
AD6 I/O Address data bus 6
51 P07 I/O Input/output port
AD7 I/O Address data bus 7
52 P10 I/O Input/output port
AD8 I/O Address data bus 8
A8 O Address bus 8
53 P11 I/O Input/output port
AD9 I/O Address data bus 9
A9 O Address bus 9
54 P12 I/O Input/output port
AD10 I/O Address data bus 10
A10 O Address bus 10
Pin No Symbol I/O Function
