KD-LH3150, KD-LH3100
(No.49838)1-57
78 P37 I/O Input/output port (with pull up)
79 P40 I/O Input/output port (with pull up)
CS0
O Chip select 0
80 P41 I/O Input/output port (with pull up)
CS1
O Chip select 1
81 P42 I/O Input/output port (with pull up)
CS2 O Chip select 2
82 P43 I/O Input/output port (with pull up)
CS3
O Chip select 3
83 P60 I/O Input/output port
SCK I/O Clock input/output (SIO mode of serial bus interface)
84 P61 I/O Input/output port
SO O Data transmitting terminal (SIO mode of serial bus interface)
Data transmit/receive terminal (I2C mode of serial bus interface)
SDA I/O Open drain output terminal
85 P62 I/O Input/output port
SI I Data receiving terminal (SIO mode of serial bus interface)
Clock input/output terminal (I2C mode of serial bus interface)
SCL I/O Open drain output terminal
86 P63 I/O Input/output port
INT0 I Interrupt request 0
87 P64 I/O Input/output port
SCOUT O System clock output
88 P65 I/O Input/output port
89 DVCC - Power supply
90 P66 I/O Input/output port
91 DVSS - Ground
92 P50 I Input port
AN0 I AD converter input
93 P51 I Input port
AN1 I AD converter input
94 P52 I Input port
AN2 I AD converter input
95 P53 I Input port
AN3 I AD converter input
ADTRG
I External start request for AD converter
96 P54 I Input port
AN4 I AD converter input
97 P55 I Input port
AN5 I AD converter input
98 P56 I Input port
AN6 I AD converter input
99 P57 I Input port
AN7 I AD converter input
100 VREFH I Reference power supply input for AD converter (H)
Pin No Symbol I/O Function
