KD-LH3150, KD-LH3100
(No.49838)1-59
46 E2PROM-DO O I2C data output
47 E2PROM-CLK O I2C clock output
48 OPEN I DOOR OPEN SW
49 DETACH I Detach detect input; H means detaching
50 NC - Not use
51 to 53 NC - Not use
54 EQ-CLK O Clock output for e-EQ IC
55 EQ-DA O Data output for e-EQ IC
56 EQ-LA O Latch output for e-EQ IC
57 to 59 NC - Not use
60 RDS DA I Not use
61 SD/ST I Station detector or stereo indicator input;
H means a station is there, L means the program is stereo.
62 AFCK O Not use
63 SEEK/STOP O Auto seek and stop selecting output;
H means seeking, L means receiving.
64 CF SEL O Wide & Narrow
65 FM/AM O FM, AM band selecting output; H=FM, L=AM
66 PLL-CE O CE output for PLL IC
67 PLL-DO O Data output for PLL IC
68 PLL-CLK O Clock output for PLL IC
69 PLL-DI I Data input from PLL IC
70 TEL-MUTING I Telephone muting detection input;
Active level can be selected H or L in PSM
71 DIM-OUT O Dimmer detector output
72 VSS - Ground
73 DIM-IN I Dimmer detector input L=dimmer on
74 PS1 I Power save1 L=ACC off
75 POWER O Power on/off control output H=power on
76 CD-ON - Not use
77 MUTING O Muting output L=muting on
78 CD MUTING I CD mute input L=mute on
79 CD RESET O CD reset control out H=reset on
80 LINE SEL I Feature selection H: line input (U57:not support), L: support
81 VDD - Power supply
82 NC - Not use
83 VOL-DA O Data output for e-vol IC
84 VOL-CLK O Clock output for e-vol IC
85 WOOFER SEL I Feature selection H:support L:Not support
86 SUB MUTING O Muting control output for subwoofer
87 LPF1 O LPF control1
88 LPF2 O LPF control2
89 STAGE2 I Feature selection H: R or Do L: J or U
90 STAGE1 I Feature selection H: R or U L: J or Do
91 to 93 NC - Not use
94 TEST For rewriting flash memory
95 to 100 NC - Not use
Pin No. Symbol I/O Function
