JVC MX-JD3 Service Manual

1-28 (No.MB191)
3.4 Speaker section
3.4.1 Removing the net assembly
(See Fig.1)
(1) From the front side of the speaker main body, remove the
sections a of the net assembly toward this side.
Fig.1
Net assembly
a
aa
a
aa
