JVC MX-JD3 Service Manual

3-4
General Assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 GV10220-006A FRONT PANEL ASS UE
1 GV10220-003A FRONT PANEL ASS
UN,U
S,UX
2 GV30576-003A FL LENS
3 GV20277-002A FRONT COVER
4 GV30577-001A FUNC.INDICATOR
5 GV40485-002A REMOTE LENS
6 GV40486-002A INDICATOR LENS (x2)
7 GV30580-001A VOLUME KNOB
8 LV42979-002A VOLUME RING
9 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
10 GV40083-004A MIC.KNOB
UN,U
S,UX
11 GV30583-002A TRAY FITTING
12 QYSDSF2608Z SCREW 2.6mm x 8mm(x6)
13 QYSDSF2608Z SCREW 2.6mm x 8mm(x13)
14 GV40246-001A FOOT SPACER (x2)
15 GV40246-002A FOOT SPACER (x2)
16 GV10206-001A CENTER CHASSIS
17 GV20275-001A STAY BRACKET
18 CMAT5Z226 CASS.MECHA
19 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x2)
20 QYSBSG3008Z TAPPING SCREW 3mm x 8mm
21 E310243-002 PLASTIC RIVET
22 QYSDSF2608Z SCREW 2.6mm x 8mm(x6)
23 GV40512-002A FL FILTER
24 GV40496-001A SWING CAM(L)
25 GV40497-001A SWING CAM(R)
26 GV40501-001A SWING CAM (x2)
27 GV40502-002A SPRING (x2)
28 GV40503-001A WASHER (x2)
29 GV40504-001A SCREW (x2)
30 GV10204-001A CASS.HOLDER(L)
31 GV10205-001A CASS.HOLDER(R)
32 GV20278-004A CASS.COVER (L)
33 GV20279-004A CASS.COVER (R)
34 GV40487-001A CASS.LENS (x2)
35 GV40489-001A DOOR SPRING(L)
36 GV40490-001A DOOR SPRING(R)
37 GV40034-001A DAMPER ASSY. (x2)
38 VKY4180-401 CASSETTE SPRING (x4)
39 QYSBSF3010Z TAP SCREW 3mm x 10mm(x6)
40 GV40515-001A METAL PIN (x2)
41 QYSBSF3012Z TAP SCREW 3.0mm x 12mm(x3)
42 LV30225-011A SPACER
43 LV30225-011A SPACER
44 LV30225-011A SPACER
45 LV30225-011A SPACER
46 GV10209-001A BOTTOM CHASSIS
47 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
48 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
49 GV10217-003A METAL COVER
50 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
51 QYSDSTL4008Z ASSY SCREW 4mm x 8mm(x4)
52 GV30581-002A HEAT SINK
53 GV40488-001A LEAF SPRING
54 QYSBSG3014E TAP SCREW 3mm x 14mm(x2)
55 QYSBSG3014E TAP SCREW 3mm x 14mm(x2)
56 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
57 QZW0033-001 STRAIN RELIEF
58 QYSBSG3010Z TAPPING SCREW 3mm x 10mm
59 QYSBSG3014E TAP SCREW 3mm x 14mm
60 GV40327-002A IC BRD.HOLDER
61 QYSSST3006Z SCREW 3mm x 6mm(x2)
63 GV30349-003A SPACER (x2)
64 E3400-431 SPECER
65 GV10207-014A REAR PANEL UE
65 GV10207-013A REAR PANEL
UN,U
S
65 GV10207-012A REAR PANEL UX
66 GV10208-001A REAR COVER
67 QAU0347-001 TUNER UE
67 QAU0346-001 TUNER
UN,U
S,UX
68 QYSBSF3035Z TAP SCREW M3 x 35mm(x2)
69 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
UN,U
S,UX
70 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
71 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
72 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
73 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
74 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
75 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
76 QYSBSF3012E SPECIAL SCREW 3mm x 12mm(x2)
77 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
78 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x3)
79 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
80 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
81 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
82 QYSDSG3006N TAP SCREW M3 x 6mm(x2)
83 LV41843-002A LASER CAUTION
 84 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK
UE,U
N,US
 84 QMPR290-200-JN POWER CORD(EU) 2m BLACK UX
 85 QQT0437-001 POWER TRANSF
86 QAR0317-001 FAN
87 QUQH12-1108AJ CARD WIRE FC21
88 QUQH12-1314AJ FFC WIRE FC303
89 QUQH12-1714BJ CARD WIRE FC860
90 QUQH10-1730BJ CARD WIRE FC513
91 QUQH10-1920BJ CARD WIRE FC511
92 QUQH10-0541BJ CARD WIRE FC11
93 QUQH12-1211AJ CARD WIRE FC880
94 QUQH12-1210AJ CARD WIRE FC410
95 WJN0074-003A SIGNAL WIRE FW301
96 WJZ0137-001A S.WIRE TW992
 97 QMF51W2-4R0-J8 FUSE F001 4A AC250V
 98 QMF51W2-2R0-J8 FUSE F003 2A AC250V
 99 QMF51W2-3R15-J8 FUSE
F101 3.15A
AC250V
 100 QMF51W2-3R15-J8 FUSE
F102 3.15A
AC250V
 101 QMF51W2-2R0-J8 FUSE F103 2A AC250V
 102 QMF51W2-3R15-J8 FUSE
F104 3.15A
AC250V
103 GV30507-001A FL HOLDER
104 GV30349-021A SPACER (x2)
105 QLF0136-001 FL TUBE FL910
 Symbol No. Part No. Part Name Description Local
