JVC MX-JD3 Service Manual

3-14
Front board
Block No. [0][3][0][0]
R908 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
VR320 QVP0004-203Z TRIM RESISTOR 20k Ω
L317 QQL244K-100Z COIL 10uH K
L320 QQR1118-002 OSC COIL(BIAS)
L812 QQL231K-2R2Y COIL 2.2uH K
L813 QQL231K-2R2Y COIL 2.2uH K
CN11 QGF1036C1-05 CONNECTOR FFC/FPC (1-5)
CN21 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN211 QGB2510K1-09 CONNECTOR B-B (1-9)
CN216 QGB2510J1-11 CONNECTOR B-B (1-11)
CN220 QGD2504C1-03Z CONNECTOR (1-3)
CN221 QGD2504C1-03Z CONNECTOR (1-3)
CN301 QGA2001C1-07 CONNECTOR W-B (1-7)
CN302 QGA2001C1-03 CONNECTOR W-B (1-3)
CN303 QGF1205C1-13 CONNECTOR FFC/FPC (1-13)
CN410 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
CN511 QGF1036C1-19 CONNECTOR FFC/FPC (1-19)
CN513 QGF1036C1-17 CONNECTOR FFC/FPC (1-17)
CN800 QGF1205F1-07 CONNECTOR FFC/FPC (1-7)
CN860 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
CN880 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
HS420 LE40505-001A HEAT SINK
J454 QNN0420-001 SURROUND JACK
UN,U
S,UX
J812 QNS0089-001 3.5 JACK
J814 GP1FA553TZ OPT TRANSMITTER
PP301 QZW0038-001 WIRE CLAMP
TW400 QUB230-06A4A4 WIRE
X801 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
IC900 SN74HCU04N FL DRIVER
IC920 PT6305 FL DRIVER
IC930 GP1UM281XK IR DETECT UNIT 38kHz
IC970 BU9253AS IC
UN,U
S,UX
IC971 RC4580IP IC
UN,U
S,UX
Q933 KRC102M-T DIGI TRANSISTOR
Q934 KRC102M-T DIGI TRANSISTOR
Q935 KRC102M-T DIGI TRANSISTOR
Q936 KRC102M-T DIGI TRANSISTOR
Q937 KRC102M-T DIGI TRANSISTOR
Q938 KRC102M-T DIGI TRANSISTOR
Q980 KRA111M-T DIGI TRANSISTOR
UN,U
S,UX
Q981 KRA111M-T DIGI TRANSISTOR
UN,U
S,UX
Q982 KRA111M-T DIGI TRANSISTOR
UN,U
S,UX
Q987 2SC3576-JVC-T TRANSISTOR
UN,U
S,UX
 Q2010 KTC2026/OY/ TRANSISTOR
Q2011 KTC3199/GL/-T TRANSISTOR
D925 SLA-362LT-T LED
D933 SLA-362LT-T LED
D934 SLA-362LT-T LED
D935 SLA-362LT-T LED
D936 SLA-362LT-T LED
D937 SLA-362LT-T LED
D938 SLA-362LT-T LED
D957 1SS133-T2 DIODE UE
D958 1SS133-T2 DIODE UE
D971 MTZJ5.1B-T2 Z DIODE
UN,U
S,UX
D991 MTZJ2.4B-T2 Z DIODE
UN,U
S,UX
 Symbol No. Part No. Part Name Description Local
D992 1SS133-T2 DIODE
UN,U
S,UX
D994 MTZJ2.4B-T2 Z DIODE
 D2010 1N5402M-20 DIODE
 D2011 1N5402M-20 DIODE
 D2012 1N5402M-20 DIODE
 D2013 1N5402M-20 DIODE
D2015 1N4003S-T5 SI DIODE
D2016 1N4003S-T5 SI DIODE
D2017 1N4003S-T5 SI DIODE
D2018 MTZJ20B-T2 Z DIODE
D2019 MTZJ18B-T2 Z DIODE
D2020 MTZJ6.8B-T2 Z DIODE
C903 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C904 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C905 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C920 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C921 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C922 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C923 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C924 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C925 QETN1HM-226Z E CAPACITOR 22uF 50V M
C926 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C930 QETN1HM-106Z E CAPACITOR 10uF 50V M
C931 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C957 QCBB1HK-222Y C CAPACITOR 2200pF 50V K UE
C958 QCBB1HK-221Y C CAPACITOR 220pF 50V K UE
C959 QCBB1HK-221Y C CAPACITOR 220pF 50V K UE
C970 QCBB1HK-101Y C CAPACITOR 100pF 50V K
UN,U
S,UX
C971 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
UN,U
S,UX
C972 QETN1CM-107Z E CAPACITOR 100uF 16V M
UN,U
S,UX
C973 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
UN,U
S,UX
C974 QDXB1CM-472Y C CAPACITOR 4700pF 16V M
UN,U
S,UX
C975 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
UN,U
S,UX
C976 QEKC1CM-226Z E CAPACITOR 22uF 16V M
UN,U
S,UX
C977 QEKC1HM-474Z E CAPACITOR 0.47uF 50V M
UN,U
S,UX
C978 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
UN,U
S,UX
C979 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
UN,U
S,UX
C980 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
UN,U
S,UX
C981 QEKC1HM-224Z E CAPACITOR 0.22uF 50V M
UN,U
S,UX
C982 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
UN,U
S,UX
C983 QCBB1HK-151Y C CAPACITOR 150pF 50V K
UN,U
S,UX
C984 QCBB1HK-331Y C CAPACITOR 330pF 50V K
UN,U
S,UX
C985 QCBB1HK-151Y C CAPACITOR 150pF 50V K
UN,U
S,UX
C986 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
UN,U
S,UX
C987 QETN1CM-107Z E CAPACITOR 100uF 16V M
UN,U
S,UX
C988 QEKC1AM-227Z E CAPACITOR 220uF 10V M
UN,U
S,UX
C989 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
UN,U
S,UX
C990 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
UN,U
S,UX
C991 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
UN,U
S,UX
C992 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
UN,U
S,UX
C993 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
UN,U
S,UX
C994 QDXB1CM-222Y C CAPACITOR 2200pF 16V M
C995 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C996 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C997 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
 Symbol No. Part No. Part Name Description Local
