(No.MB504)1-3
Europian version
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency?32 kHz, 44.1 kHz, 48 kHz)
Designs and specifications are subject to change without notice.
Amplifier
Output Power Front channels 100 W per channel, min. RMS, driven into 8
Ω, at 1 kHz with no more than 10%
total harmonic distortion.
Center channel 100 W, min. RMS, driven into 8
Ω, at 1 kHz with no more than 10% total harmon-
ic distortion.
Surround channels 100 W per channel, min. RMS, driven into 8
Ω, at 1 kHz with no more than 10%
total harmonic distortion.
Audio Audio Input Sensitivity/Impedance (1 kHz) CD, TAPE/CDR, VCR, TV SOUND, DVD, AUX : 220 mV/47 k
Ω
Audio Input (DIGITAL IN) Coaxial DIGITAL 1 (DVD) : 0.5 V(p-p)/75 Ω
Optical DIGITAL 2 (CD) : -21 dBm to -15 dBm (660 nm ±30 nm)
Recording Output Level TAPE/CDR, VCR : 220 mV
Signal-to-Noise Ratio ('66 IHF/DIN) CD, TAPE/CDR, VCR, TV SOUND, DVD : 66 dB/62 dB
Frequency Response (8
Ω) CD, TAPE/CDR, VCR, TV SOUND, DVD, AUX : 20 Hz to 20 kHz (±1 dB)
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz : ±8 dB (in 2 dB steps)
Video Video Input Sensitivity/Impedance Composite video DVD, VCR, AUX : 1 V(p-p)/75
Ω
Video Output Level Composite video VCR, MONITOR OUT : 1 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural 17.0 dBf (1.9
µV/75 Ω)
50 dB Quieting Sensitivity Monaural 21.3 dBf (3.2
µV/75 Ω)
Stereo 41.3 dBf (31.8
µV/75 Ω)
Stereo Separation at OUT (REC) 35 dB at 1 kHz
AM (MW) tuner
Tuning Range 522 kHz to 1 629 kHz
General
Power Requirements AC 230 V , 50 Hz
Power Consumption 140 W (at operation)
0.8 W (in standby mode)
Dimensions (W
× H × D) 435 mm × 146.5 mm × 369.5 mm
Mass 7.0 kg
