3-12
DSP board
Block No. [0][4]
R1462 QRJ146J-2R2X UNF C RESISTOR 2.2
Ω
1/4W J
R1464 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1470 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R1471 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R1472 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1473 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1474 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1475 NRSA63J-163X MG RESISTOR 16k
Ω
1/16W J
R1476 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1477 QRZ9006-4R7X FUSI RESISTOR 4.7
Ω
R1480 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1481 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1482 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1483 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R1484 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1485 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
R1486 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1487 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1488 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1489 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
R1490 NRSA63J-133X MG RESISTOR 13k
Ω
1/16W J
R1491 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1492 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1494 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1496 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R1498 NRSA63J-511X MG RESISTOR 510
Ω
1/16W J
R1499 NRSA63J-511X MG RESISTOR 510
Ω
1/16W J
R1500 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R1571 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1572 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1575 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1576 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1579 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1580 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R1583 NRSA63J-511X MG RESISTOR 510
Ω
1/16W J
R1584 NRSA63J-511X MG RESISTOR 510
Ω
1/16W J
BK701 LV42093-001A FL HOLDER(L)
BK702 LV42092-001A FL HOLDER(R)
CN421 QGB2510J1-15 CONNECTOR B-B (1-15)
CN431 QGB2510J1-06 CONNECTOR B-B (1-6)
CN441 QGB2510J1-06 CONNECTOR B-B (1-6)
CN471 QGA2501C3-03Z CONNECTOR W-B (1-3)
CN472 QGA2501C1-02 CONNECTOR W-B (1-2)
CN473 QGA2501C3-03Z CONNECTOR W-B (1-3)
CN481 QGB2510J1-14 CONNECTOR B-B (1-14)
CN482 QGB2510J1-07 CONNECTOR B-B (1-7)
CN491 QGB2510J1-04 CONNECTOR B-B (1-4)
CN704 WJS0020-002A-E SKT.WIRE ASSY
CN714 QGA2001F1-03 CONNECTOR W-B (1-3)
DI701 QLF0132-001 FL TUBE
EP401 QNZ0136-001Z IM EARTH PLATE
EP402 QNZ0136-001Z IM EARTH PLATE
HS401 E70306-001 HEAT SINK
HS402 E70306-001 HEAT SINK
HS403 E70306-001 HEAT SINK
HS404 E70306-001 HEAT SINK
HS434 E70306-001 HEAT SINK
HS435 E70306-001 HEAT SINK
JS701 QSW1017-002 JOG VOLUME
JS702 QSW1051-001 ROTARY ENCODER
S721 QSW0683-001Z PUSH SW I.M
S722 QSW0683-001Z PUSH SW I.M
S723 QSW0683-001Z PUSH SW I.M
S724 QSW0683-001Z PUSH SW I.M
S725 QSW0683-001Z PUSH SW I.M
S726 QSW0683-001Z PUSH SW I.M
S727 QSW0683-001Z PUSH SW I.M
S728 QSW0683-001Z PUSH SW I.M
S729 QSW0683-001Z PUSH SW I.M
S730 QSW0683-001Z PUSH SW I.M
S731 QSW0683-001Z PUSH SW I.M
S732 QSW0683-001Z PUSH SW I.M
S734 QSW0683-001Z PUSH SW I.M
S735 QSW0683-001Z PUSH SW I.M
S736 QSW0683-001Z PUSH SW I.M
S738 QSW0683-001Z PUSH SW I.M
S739 QSW0683-001Z PUSH SW I.M
Symbol No.
Part No. Part Name Description Local
S740 QSW0683-001Z PUSH SW I.M
S741 QSW0683-001Z PUSH SW I.M
S742 QSW0683-001Z PUSH SW I.M
S743 QSW0683-001Z PUSH SW I.M
S745 QSW0683-001Z PUSH SW I.M
S746 QSW0683-001Z PUSH SW I.M
S750 QSW0683-001Z PUSH SW I.M
S751 QSW0683-001Z PUSH SW I.M
S752 QSW0683-001Z PUSH SW I.M
S757 QSW0683-001Z PUSH SW I.M
X701 QAX0246-001Z RESONATOR
Symbol No.
Part No. Part Name Description Local
IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
IC613 NJM4565M-WE IC
IC615 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC661 DSPC56371AF180 IC
IC662 SN74LVC1GU04K-X IC
IC667 CS42518-CQZ-C-W IC
IC671 UPD784215AGC284 IC
IC672 SN74AHCT1G32K-X IC
IC673 SN74LVC1G04K-X IC
IC691 BA3259HFP-W IC
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SC3928A/RS/-X TRANSISTOR
Q2142 2SC3928A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SC3928A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2701 KRC107S-X DIGI TRANSISTOR
Q2702 KRC107S-X DIGI TRANSISTOR
Q2703 KRC107S-X DIGI TRANSISTOR
Q2704 KRA107S-X TRANSISTOR
Q2705 KRA107S-X TRANSISTOR
Q2706 KRA107S-X TRANSISTOR
Q2708 KRA107S-X TRANSISTOR
Q2709 KRA107S-X TRANSISTOR
Q2710 KRC107S-X DIGI TRANSISTOR
C2001 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C2002 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C2005 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2006 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2018 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2101 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2109 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2110 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
Symbol No.
Part No. Part Name Description Local
