1-2 (No.MB504)
SPECIFICATION
Northern america version
Amplifier
Output Power Front channels 100 W per channel, min. RMS, driven into 8
Ω, at 1 kHz with no more than 10%
total harmonic distortion.
Center channel 100 W, min. RMS, driven into 8
Ω, at 1 kHz with no more than 10% total harmon-
ic distortion.
Surround channels 100 W per channel, min. RMS, driven int 8
Ω, at 1 kHz with no more than 10%
total harmonic distortion.
Audio Audio Input Sensitivity/Impedance (1 kHz) CD, TAPE/CDR, VCR, TV SOUND, DVD, AUX : 220 mV/47 k
Ω
Audio Input (DIGITAL IN)* Coaxial DIGITAL 1 (DVD) : 0.5 V(p-p)/75 Ω
Optical DIGITAL 2 (CD) : -21 dBm to -15 dBm (660 nm ±30 nm)
Recording Output Level TAPE/CDR, VCR : 220 mV
Signal-to-Noise Ratio ('66 IHF/'78 IHF) CD, TAPE/CDR, VCR, TV SOUND, DVD : 62 dB/71 dB
Frequency Response (8
Ω) CD, TAPE/CDR, VCR, TV SOUND, DVD, AUX : 20 Hz to 20 kHz (±1 dB)
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz : ±8 dB (in 2 dB steps)
Video Video Input Sensitivity/Impedance Composite video DVD, VCR, AUX : 1 V(p-p)/75
Ω
Video Output Level Composite video VCR, MONITOR OUT : 1 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
FM tuner (IHF)
Tuning Range 87.5 MHz to 108.0 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2
µV/75 Ω)
50 dB Quieting Sensitivity Monaural 16.0 dBf (1.7
µV/75 Ω)
Stereo 37.5 dBf (20.5
µV/75 Ω)
Stereo Separation at OUT (REC) 35 dB at 1 kHz
AM tuner
Tuning Range 530 kHz to 1 710 kHz
General
Power Requirements AC 120V , 60 Hz
Power Consumption 155 W/200 VA (at operation)
0.8 W (in standby mode)
Dimensions (W
× H × D) 435 mm × 146.5 mm × 369.5 mm
Mass 7.0 kg
