JVC RX-5060BJ User Manual

3-10
Front board
Block No. [0][3]
FW301 QUM215-26Z3Z3-E PARA RIBON WIRE
FW302 QUM216-26Z3Z3-E PARA RIBON WIRE
FW303 QUM214-26DGZ3-E PARA RIBON WIRE
J101 QNS0249-001 JACK
J402 QNN0478-001 PIN JACK
J403 QNN0478-001 PIN JACK
J404 QNN0389-001 PIN JACK
J406 QNN0480-001 PIN JACK
 RY302 QSK0127-001 RELAY
 RY303 QSK0127-001 RELAY
 RY304 QSK0127-001 RELAY
ST301 QNB0188-001 SPEAKER TERMINA
TW301 QUB230-05DMZ4-E SIN TWIST WIRE
 Symbol No. Part No. Part Name Description Local
PW502 QUB220-12DMHP-E SIN TWIST WIRE
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
IC422 NJM4565M-WE IC
IC427 NJM4565M-WE IC
IC428 BD3814FV-X IC
IC701 MN101C88GPA IC
5060BJ,
5060BC
IC701 MN101C88GPC IC
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
IC702 IC-PST9139-T IC
IC703 GP1UM281XKVF IR DETECT UNIT
IC704 BR24L02F-W-X IC
Q701 KRC107S-X DIGI TRANSISTOR
Q702 KRC111S-X TRANSISTOR
5060BJ,
5060BC
Q703 KRC109S-X TRANSISTOR
5060BJ,
5060BC
Q707 KRC107S-X DIGI TRANSISTOR
Q708 KRC107S-X DIGI TRANSISTOR
Q709 KRC107S-X DIGI TRANSISTOR
Q711 KRA104S-X DIGI TRANSISTOR
 Q1401 KTA1046/Y/ TRANSISTOR *
 Q1402 2SD2394/EF/ TRANSISTOR
 Q1403 2SD2394/EF/ TRANSISTOR
 Q1404 2SD2394/EF/ TRANSISTOR
 Q1407 KTC3203/OY/-T TRANSISTOR
 Q1408 KTA1271/OY/-T TRANSISTOR
Q1413 2SC3576-JVC-T TRANSISTOR
Q1414 2SC3576-JVC-T TRANSISTOR
Q1417 2SC3576-JVC-T TRANSISTOR
Q1418 2SC3576-JVC-T TRANSISTOR
Q1419 2SC3576-JVC-T TRANSISTOR
Q1420 KRA104M-T DIGI TRANSISTOR
Q1421 2SC3576-JVC-T TRANSISTOR
Q1422 2SC3576-JVC-T TRANSISTOR
Q1423 KRA104M-T DIGI TRANSISTOR
Q1424 KRA104M-T DIGI TRANSISTOR
Q1426 2SC3576-JVC-T TRANSISTOR
Q1427 2SC3576-JVC-T TRANSISTOR
Q1428 2SC3576-JVC-T TRANSISTOR
Q1429 KRA104M-T DIGI TRANSISTOR
 Q1434 2SD2394/EF/ TRANSISTOR
 Q1435 2SD2394/EF/ TRANSISTOR
D701 1SS355W-X SI DIODE
D703 1SS355W-X SI DIODE
D704 1SS355W-X SI DIODE
D719 SLR-343VC/NPQ-T LED
D1401 MTZJ11A-T2 Z DIODE
D1402 MTZJ6.2C-T2 Z DIODE
D1403 MTZJ5.6B-T2 Z DIODE
 Symbol No. Part No. Part Name Description Local
D1404 MTZJ5.6C-T2 Z DIODE
D1405 MTZJ11A-T2 Z DIODE
D1407 MTZJ7.5C-T2 Z DIODE
D1408 MTZJ7.5C-T2 Z DIODE
D1409 MA152WK-X SI DIODE
D1411 1SS355W-X SI DIODE
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
D1412 1SS355W-X SI DIODE
D1413 1SS355W-X SI DIODE
D1414 1SS355W-X SI DIODE
D1415 1SS355W-X SI DIODE
C701 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C702 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C703 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C704 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C705 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C706 NCB21HK-331X C CAPACITOR 330pF 50V K
5060BJ,
5060BC
C707 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C708 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C709 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C710 NCB21HK-104X C CAPACITOR 0.1uF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C713 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C714 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C715 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C716 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C717 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C718 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C719 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C720 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C721 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C722 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C723 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C724 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C725 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C730 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C731 NCB21HK-104X C CAPACITOR 0.1uF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C732 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C733 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C734 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C735 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C736 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1401 QETN1HM-476Z E CAPACITOR 47uF 50V M
C1402 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1403 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1404 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1405 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1406 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C1408 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1409 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1413 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1414 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1416 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1417 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1422 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1423 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1424 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1425 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C1432 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1433 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C1436 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1437 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C1447 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1459 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1460 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1461 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C1465 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C1480 QETN1VM-477Z E CAPACITOR 470uF 35V M
 Symbol No. Part No. Part Name Description Local
