JVC RX-5060BJ User Manual

3-7
Amplifier board
Block No. [0][2]
FC272 QNG0020-001Z FUSE CLIP I.M
FW201 QUM215-14Z3Z3-E PARA RIBON WIRE
FW251 QUM213-08DGZ3-E PARA RIBON WIRE
J501 QNN0011-001 PIN JACK
J502 QNN0011-001 PIN JACK
J521 QNS0089-001 3.5 JACK
5060BJ,
5060BC
J901 QNN0772-001 PINJACK
K901 QQR1183-001Z FERRITE BEADS
5060BJ,
5060BC
 RY202 QSK0128-001 RELAY
 RY203 QSK0127-001 RELAY
TA201 QNZ0079-001Z TAB I.M
TA202 QNZ0079-001Z TAB I.M
 Symbol No. Part No. Part Name Description Local
PW401 QUB220-12DMHP-E SIN TWIST WIRE
 IC101 STK412-400 IC
 IC102 STK413-400 IC
IC402 BD3841FS-X IC
Q1131 KTC3200/GL/-T TRANSISTOR
Q1132 KTC3200/GL/-T TRANSISTOR
Q1171 KTC3200/GL/-T TRANSISTOR
Q1172 KTA1268/GL/-T TRANSISTOR
Q1173 KTC3199/GL/-T TRANSISTOR
 Q1175 KTA1046/Y/ TRANSISTOR *
Q1185 KTA1268/GL/-T TRANSISTOR
Q1231 KTC3200/GL/-T TRANSISTOR
Q1232 KTC3200/GL/-T TRANSISTOR
Q1261 KTC3200/GL/-T TRANSISTOR
 D1101 UF304G-F82 DIODE
 D1102 UF304G-F82 DIODE
 D1103 UF304G-F82 DIODE
 D1104 UF304G-F82 DIODE
 D1105 UF304G-F82 DIODE
 D1106 UF304G-F82 DIODE
 D1107 UF304G-F82 DIODE
 D1108 UF304G-F82 DIODE
D1121 MTZJ15C-T2 Z DIODE
D1122 MTZJ15C-T2 Z DIODE
D1129 1SS133-T2 DIODE
D1130 1SS133-T2 DIODE
D1141 MTZJ36C-T2 Z DIODE
D1171 1SS133-T2 DIODE
D1221 MTZJ15C-T2 Z DIODE
D1222 MTZJ15C-T2 Z DIODE
D1229 1SS133-T2 DIODE
D1230 1SS133-T2 DIODE
D1261 1SS133-T2 DIODE
D1352 1SS133-T2 DIODE
D1353 1SS133-T2 DIODE
D1354 1SS133-T2 DIODE
C101 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BJ,
5060BC
C101 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C102 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BJ,
5060BC
C102 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C418 QCBB1HK-561Y C CAPACITOR 560pF 50V K
C419 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C420 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
 Symbol No. Part No. Part Name Description Local
C421 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C422 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C423 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C424 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C425 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C426 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C427 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C428 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C429 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C430 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C431 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C432 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C433 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C434 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C435 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C436 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C437 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C438 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C443 QETN1EM-476Z E CAPACITOR 47uF 25V M
C444 QETN1EM-476Z E CAPACITOR 47uF 25V M
C451 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C452 QCBB1HK-331Y C CAPACITOR 330pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C460 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
5060BE,
5062SE,
5062SB,
5062SE
N,5062S
EV
C1101 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1102 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1103 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1104 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C1105 QETN1AM-227Z E CAPACITOR 220uF 10V M
C1106 QETN1AM-227Z E CAPACITOR 220uF 10V M
C1107 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C1108 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
 Symbol No. Part No. Part Name Description Local
