Page #39 background image
(No.22036)1-39
37 NC - Not use
38 NC - Not use
39 NC - Not use
40 LEDRV O LED indicate Reverse
41 LEDREC O LED indicate REC
42 LEDFR O LED indicate Forward
43 STTA O Tape strobe
44 DATA O LCD data
45 MODE O LCD data mode control
46 SCL O LCD serial clock
47 NC - Not use
48 PHOTO I Tape end detection
49 INH O LCD driver inhibit ('L' at end of transmission)
50 LCDCE - LCD chip enable
51 DIMMER - Dimmer control
52 VOL+ I Volumn plus
53 LEDCTL O Power standby LED control
54 BASS- I Bass minus
55 VOL- I Volumn minus
56 BASS+ I Bass plus
57 TUST/CE O Tuner PLL strobe
58 FTUNER O Tuner function ('H'=TUNER)
59 BUP O Back up power detect ('H'=BACKUP)
60 RESET - Reset signal
61 REM I Remote control input
62 RDSCK I RDS clock
63 MPX I FM stereo detection ('L'=STEREO)
64 NC - Not use
65 +BCTL - Not use
66 BLKCL I Block clock input port
67 VSS0 - GND
68 VDD - Power supply
69 X2 - Not use
70 X1 - Not use
71 IC - GND
72 XT2 - Not use
73 XT1 - Not use
74 AVDD - Power supply
75 AVREF0 - Reference voltage
76 SAFETY1 I Irregular voltage detection 1
77 TAPE0 I Tape Switch 0
78 TAPE1 I Tape Switch 1
79 KEY0 I Unit Key input 1
80 KEY1 I Unit Key input 0
Pin No. Symbol I/O Function
