JVC UX-P55 Service Manual

1-6 (No.22036)
SECTION 2
Disassembly method
2.1 Main body
2.1.1 Removing the metal cover
(See Fig.1, 2)
(1) Remove the six screws A on the back of the body.
(2) Remove the two screws B on the side of the body.
(3) Pull both sides of the metal cover outward and lift the rear
part of the cover.
Fig.1
Fig.2
A
Metal cover
A
A
A
A
Metal cover
B x 2
