Kaadas K20 Pro - Exploded View of Components

13
5 6 7 8 9 10 11
1 2
12
3 4
Explosive view
The explosive view helps you understand better the construction the lock.
1、Inside display screen
2、Lithium battery
3、M6 screw (2pcs)
4、Back panel components
5、M5 screw (2pcs)
6、mounting plate
7、Mortise
8、tailpiece
9、M6 connecting screw post (2pcs)
10、M5 connecting screw post (2pcs)
11、Front panel components
12、rubber plug
13、Mortise screw（4pcs）
