26
Visual Feedback Message Definitions
C
ondition Parameters
Green LED Red LED Duration Rate
V
alid pushbutton ON OFF 1/10 sec Once
pressed
Timeout expired OFF ON 1 sec; A Once
Valid access ON OFF 1 sec Once
code keyed
Access granted ON OFF 1/10 sec 1 sec
Access granted ON ON 1/10 sec 1 sec
(battery low condition
Access denied OFF ON 1 sec; A Once; B
Valid programming ON OFF 1 sec Once
entry
Invalid programming OFF ON 1 sec; A Once; B
entry (including
duplicate access code)
Tamper shutdown OFF ON 2 sec Once
beginning
Tamper shutdown state OFF ON 1 sec; C 10 sec
Tamper shutdown ON OFF 2 sec; C Once
ending
For EPS2000 only:
Lock is ready when front ON OFF 1/10 sec Once
lever is depressed
Lock’s stored power is OFF ON 1/10 sec 1 sec
starting to fade
A = 1/10 second; B = Twice; C = Can be observed only when you pump the lock’s lever
