Error Code Indication
The components of the eBike system are continuously and au-
tomatically monitored. When an error is detected, the respec-
tive error code is indicated in text indication c.
To return to the standard indication, press any button on the
drive HMI 3 or on the operating unit 10.
Depending on the type of error, the drive is automatically shut
off if required. Continued travel without assistance from the
drive is possible at any time
. H
owever, have the eBike
checked before attempting new trips.
Have all inspections and repairs carried out only by an
authorised bicycle dealer. When an error is still displayed
despite corrective measures, please also refer to an
authorised bicycle dealer.
Power Supply of External Devices via USB
Connection
With the USB connection, it is possible to operate and charge
most devices whose power supply is possible via USB (e.g.,
various mobile phones).
Prerequisite for the charging is that the drive HMI and a suffi-
ciently charged battery pack are inserted in the eBike.
Open the protective cap 8 of the USB port on the drive HMI.
Using a matching USB cable, connect the USB port of the ex-
ternal device to the U
SB port 7 of th
e drive HMI.
Code Cause Corrective Measure
100
Internal error of the drive unit Have the drive unit checked
101
Connection problem of the drive unit Have connections and contacts checked
102
Error of the speed sensor Have the speed sensor checked
103*
Connection problem of the lighting
system
Have connections and contacts checked
104
Connection problem of the drive HMIHave connections and contacts checked
105
Temperature of the drive unit too high
(above 40 °C)
Allow the drive unit to cool down. Continued travel without assistance
from the eBike drive is possible and speeds up the cooling of the drive
unit.
200
Internal electronic error of battery
pack
Have battery pack checked
201
Temperature of the battery pack too
high (above 40 °C)
Allow the battery pack to cool down. Continued travel without eBike drive
is possible and speeds up the cooling of the battery pack.
202
Temperature of the battery pack too
low (below –10 °C)
Allow the battery pack to warm up slowly in a warm location.
203
Connection problem of battery pack Have connections and contacts checked
204
Incorrect polarity of battery pack Charge the battery pack with the original Bosch charger as described in
the operating instructions.
410
One or more buttons of the drive HMI
are blocked.
Check if any buttons are blocked, e.g. from dirt or debris. Clean the
buttons, if required.
414
Connection problem of the operating
unit
Have connections and contacts checked
418
One or more buttons of the operating
unit are blocked.
Check if any buttons are blocked, e.g. from dirt or debris. Clean the
buttons, if required.
422
Connection problem of the drive unit Have connections and contacts checked
423
Connection problem of battery pack Have connections and contacts checked
424
Communication error among the com-
ponents
Have connections and contacts checked
430
Internal battery pack of drive HMI
empty
Charge drive HMI (in holder or via USB port)
490
Internal error of the drive HMIHave the drive HMI checked
*only for eBike lighting via battery pack (country-specific)
