Kampmann Venkon - Page 27

Venkon
Assembly, installation and operating instructions
27
Figure Description Dimensions [mm]
3.9
6.3
7.9
6.3
1.9
Outlet box with primary air connection
61 63 66 67
A
570/
22.4
inch
870/
34.3
inch
1320/
52
inch
1670/
65.7
inch
B
530/
20.9
inch
830/
32.7
inch
1280/
50.4
inch
1630/
64.2
inch
6.3
7.9
6.3
Outlet box with hotel air opening
61 63 66 67
A
620/
24.4
inch
920/
36.2
inch
1370/
53.9
inch
1720/
67.7
inch
B
583/
23
inch
883/
34.8
inch
1333/
52.5
inch
1683/
66.3
inch
6.3
6.3
7.9
3.9
1.
9
Discharge box with primary air connection and hotel air
opening
61 63 66 67
A
620/
24.4
inch
920/
36.2
inch
1370/
53.9
inch
1720/
67.7
inch
B
583/
23
inch
883/
34.8
inch
1333/
52.5
inch
1683/
66.3
inch
19.7
6.3
7.9
Splitter noise attenuator
61 63 66 67
A
570/
22.4
inch
870/
34.3
inch
1320/
52
inch
1670/
65.7
inch
B
530/
20.9
inch
830/
32.7
inch
1280/
50.4
inch
1630/
64.2
inch
39.4
6.3
7.9
Air duct
61 63 66 67
A
570/
22.4
inch
870/
34.3
inch
1320/
52
inch
1670/
65.7
inch
B
530/
20.9
inch
830/
32.7
inch
1280/
50.4
inch
1630/
64.2
inch
6.3
7.9
9.6
8.6
8.1
7
2
Flexible pipe connection unit Ø 198 mm
61 63 66 67
A
570/
22.4
inch
870/
34.3
inch
1320/
52
inch
1670/
65.7
inch
B
530/
20.9
inch
830/
32.7
inch
1280/
50.4
inch
1630/
64.2
inch
