20 Kamstrup A/S • 55122714_A2_GB_04_2021
flowIQ® Gateway
1. flowIQ® Gateway can be ordered with a 24
VAC/VDC or 230 VAC power supply.
230 VAC
24 VAC
2. Use a power cable with a diameter of 5-8 mm.
d = 5...8 mm
3. Connect the power cable to the terminals on
the right side of flowIQ® Gateway (seen from
the front).
4. Tighten the cable clamp.
5. Assemble the top and bottom parts of
flowIQ® Gateway.
