flowIQ® Gateway
Display digits
1 2 3 4 5 6 7 8
Info N/A N/A N/A V1 N/A In-A In-B Description Response
time to
active info
Applies to
1 No voltage supply -
flowIQ® Gateway
2 Low battery level < 3 min.
9 External alarm (e.g. via KMP) < 1 sec.
1
No or invalid response from flowIQ®
meter
< 1 min.
2
Unsupported unit/resolution from
flowIQ® 2200/3200 meter or
changed unit/resolution and config
log full.
< 1 min.
3 Dry < 1 min.
flowIQ® 2200 or
3200 meter
4 Reverse < 1 min.
5 Flow above Q
4
< 1 min.
7 Burst < 1 min.
8 Leak < 1 min.
7 In-A2 Leakage in the system < 1 day
flowIQ® Gateway
8 In-A1 Leakage in the system < 1 day
9 In-A1/A2 External alarm < 5 sec.
7 In-B2 Leakage in the system < 1 day
8 In-B1 Leakage in the system < 1 day
9 In-B1/B2 External alarm < 5 sec.
The alarms and info codes are transmitted by flowIQ® Gateway via the output communication
module.
The connected flowIQ® meter's info codes are interpreted as follows by the MDM system:
Description flowIQ® Gateway flowIQ® 2200/3200
The connected meter is DRY V1 Air Dry
The connected meter has Reverse flow V1 Reverse Reverse
The connected meter has registered a Leak Leak out Leak
The connected meter has registered a Burst Burst out Burst
The connected meter has registered Flow above Q
4
V1 above Q
s
Flow above Q
4
