English 5.906-591.0 Rev. 00 (01/14) 25
Danger
Prior to all work on the appliance, switch off the appliance
and pull the power plug.
Safety devices serve to protect the user and must not be
rendered in operational or their functions bypassed.
The appliance switch prevents unintentional operation of
the appliance.
AH Service group electrics
010 Safety information
020 Overview
Circuit diagram
M1 Pump motor
C1 Capacitor
S1 Power switch
F1 Thermal switch
030 Function
Power switch
