Kärcher K 7 Compact - Technical Documentation; Technical specifications

28 English 5.906-591.0 Rev. 00 (01/14)
Subject to technical modifications!
*The max. flow rate is derived from the measurement with-
out the backflow valve installed.
No data.
When working on the device, please always use the cur-
rent circuit diagram in DISIS.
Technical Documentation
Appliance type Appliance no. Circuit diagram Operating instruc-
tions
Spare parts list
K 6.200 1.446-000.0
1.446-001.0
0.089-226.0 5.964-673.0
5.965-054.0
5.972-214.0
K 7.200 1.447-000.0
1.447-001.0
0.089-226.0 5.964-673.0
5.965-054.0
5.971-607.0
K 7 Compact 1.447-002.0
1.447-003.0
1.447-004.0
0.089-226.0 5.965-162.0 5.971-607.0
Technical specifications
K 6.200 K 7.200 K 7 Compact
Electrical connection
Voltage 230
1~50
V
Hz
Connected load 2,5 3,0 3,0 kW
Protection class IP X5
Protective class I
Mains fuse (slow-blow) 16 A
Water connection
Max. feed pressure 0,6 MPa
Max. feed temperature 60 °C
Min. feed volume 12 I/min
Max. Suction height 1,0 m
Performance data
Working pressure 13 15 15 MPa
Max. permissible pressure 15 16 16 MPa
Water flow rate 8,8 9,2 9,2 I/min
Recoil force of trigger gun 20 22 22 N
Detergent flow rate 0 - 0,3 I/min
Dimensions and weights
Length 552 mm
Width 290 mm
Height 333 mm
Weight, ready to operate with accessories 17,0 18,7 19,2 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
< 2,5
0,3
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
77
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty K
WA
93 94 93 dB(A)
Torques
Circuit diagram
