Chapter 4. Getting Started
4.1 Unpack and Inspect
All units have been carefully checked for their operational reliability before shipment.
 Immediately after receipt, please check the outer packaging for damages or any signs of improper handling.
 Report any possible damages to the forwarder and your responsible sales representative. In such a case,
state a description of the defect, the type and the serial number of the device. IMPORTANT NOTE: Report
any in-transit damage immediately. Damage reported later shall not be recognized.
 Carefully unpack the unit to prevent any damage.
 Check the completeness of the delivery based on the packing slip and/or purchase order.
 The X0365 LTR-150 comes with the following components.
Item Description Quantity
1 LTR-150 1
2 6 ft. (2 meter) Mains Power Cord (US / EU 100 -240 VAC 50/60Hz) 2
3 Dry Block Insert (for up to 48 thermocouples, 3 IRTD, & 1 Reference Probes 1
4 Thermocouple Fixture 1
5 Insert Transport Cover 1
6 Insert Exchange Tool 1
7 Extruded Sleeves for thermocouples (16) 16
8 External Reference Control Probe 1
9 USB to Serial Communications cable (connection to Kaye hardware) 1
10 Calibration Certificate 1
11 User Manual 1
Save the packaging!
The LTR-150 is delivered in special protective packaging.
• Save the packaging for returning the instrument safely to the manufacturer for recalibration or repair.
• Use the type plate to check if the delivered unit corresponds to your order request.
4.2 Placement
Ensure that the LTR-150 storage and operation conditions described below are met:
• Only suitable for indoor use, do not use outdoors.
• Operate only in the vertical position on an even surface. The surface must be stable, clean, and dry.
IMPORTANT NOTE: If the operation positions do not conform to what is described then the structural safety
andthespeciedpropertiesoftheLTR-150isnotguaranteed.
• Sufcientclearancearoundthemachine;greaterthan3feet(1meter)inthefrontand1.5feet(0.5meters)onthe
sidesandback.Sufcientheadclearanceandfreespaceabovethemachine.
• Sufcientventilationmustbeensured.
• Donotoperatenearammablematerials.
• The ventilation openings must not be blocked or covered.
• The machine must be installed in a manner so that it can be easily switched off at any time.
• Not suitable for applications with high vibration or possible contamination
