| Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
1.1 Dry-Block Function
The LTR-150 comes standard with a dry block insert containing sixteen (16) wells for thermocouples as
well as two (2) wells for IRTD, and one (1) well for the Control Reference Probe. Each of the sixteen (16)
thermocouple wells is included with a sleeve which can accommodate upwards of three (3) thermocouples.
The sleeves are optimized to handle 22AWG thermocouples, which are similar to the ones currently utilized
in existing Kaye dry block models.
Kaye also offers additional dry blocks for calibrating specialty process or validation probes. These blocks are
easily interchangeable utilizing the supplied insert tool.
Thermocouple insert wells
IRTD insert wells
Control Reference Probe well
Chapter 1. Product Overview
