KEB COMBIVERT F5 Series Instruction Manual

32
A
F
B D
E
A
B
D
E
E
C
+ +
PB
Frequency
Inverter
Braking
resistor
CE
filter
Dimensions
Back mount braking resis-
tors
2 x 20 awg to
the terminals
T1/T2
(white)
16 awg (red)
2 x 16 awg to the
terminals ++ / PB
(red)
Accessories
Housing -> B D E
A
[in] 3.5 3.5 5.1
B
[in] 8.7 9.8 11.4
C
[in] 1.2 1.2 1.2
D
[in] 8.4 9.5 10.8
E
[in] 0.20 0.20 0.28
F
[in] - - 5.9

KEB COMBIVERT F5 Series Specifications

General

Control Method	Vector Control, V/f Control
Protection Class	IP20
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Communication Interfaces	CAN, PROFIBUS, Modbus RTU
Cooling Method	Fan Cooled
Relative Humidity	Up to 95% (non-condensing)
