CP-Parameter
In parameter „inverter status“ the actual operating condition of the frequency inverter
is displayed. In the case of an error the current error message is displayed, even if the
display has already been reset with ENTER (error-LED on the operator is still blinking).
Status messages and information about the cause and removal are to be found in
www.keb.de => Documentation => Operating Instructions => Other => Service
informations => Error and status messages.doc.
CP.3 Inverter status
* CP.34 (do.3) = no function with F5-S in the A-housing
5. Parameter description
Dis- Parameter Setting Reso- De- Unit En- Based
play range lution fault ter on
CP.0 Password
CP.1 Encoder 1 speed
CP.2 Set value display
CP .3 Inverter state
CP.4 Apparent current
CP.5 Peak apparent current
CP.6 Actual torque display
CP.7 Actual DC voltage
CP.8 Peak DC voltage
CP .9 Out put vo ltage
CP.10 Speed contro l config.
CP.11 DSM rated torque
CP.12 DSM rated speed
CP.13 DSM rated frequency
CP.14 DSM rated current
CP.15 DSM EM K voltage const.
CP.16 DSM winding inductance
CP.17 DSM winding resistance
CP .18 DSM curr. f. zero speed
CP.19 Load mot.dependent para.
CP.20 A bsolute position enc.1
CP.21 Encoder 1 rotation
CP.22 max. reference forward
CP.23 Step value 1
CP.24 Step value 2
CP.25 acc time forward
CP.26 dec time forward
CP.27 S-curve time acc for.
CP.28 Torque reference source
CP.29 Abs. to rque reference
CP.30 KP speed
CP.31 KI speed
CP.32 Switching frequency
CP.33 Relay output 1 / function
CP.34 Relay output 2 / function
CP .35 P ro h. ro t. sto pping mo de
CP.36 E. EF stopping mode
0...9999 1 - - - ud.1
±4000 0,125 0 rpm - ru.9
±4000 0,125 0 rpm - ru.1
0...255 1 0 - - ru.0
0...6553,5 0,1 0 A - ru.15
0...6553,5 0,1 0 A - ru.16
±10000,00 0,01 0 Nm - ru.12
0...1000 1 0 V - ru.18
0...1000 1 0 V - ru.19
0...778 1 0 V - ru.20
4...6 1 4 - - cs.0
0,1...6553,5 0,1 LTK Nm - dr.27
0...32000 1 LTK rpm - dr.24
0,0...1600,0 0,1 LTK Hz - dr.25
0,0...710,0 0,1 LTK A - dr.23
0...1000 1 LTK V - dr.26
0,01...500,00 0,01 LTK mH - dr.31
0,000...50,000 0,001 LTK Ohm - dr.30
0,0...700,0 0,1 LTK A - dr.28
1...2 1 1 - E f r.10
0...65535 1 57057 - - ec .2
0...19 1 0 - - ec.6
0...4000 0,125 2100 rpm - o p.10
±4000 0,125 100 rpm - op.21
±4000 0,125 -100 rpm - op.22
0,00...300,00 0,01 5 s - o p.28
-0,01...300,00 0,01 5 s - op.30
0,00...5,00 0,01 0 s - o p.32
0...5 1 2 - E cs.15
±10000,00 0,01 LTK Nm - cs.19
0...32767 1 50 - - c s.6
0...32767 1 500 - - cs.9
0...LTK 1 LTK - E uf.11
0...78 1 4 - E do .2
0...78 1 2 - E do .3 *
0...6 1 6 - - pn.7
0...6 1 0 - - pn.3
