KEB COMBIVERT F6 Instruction Manual

GB - 7
Preface
1.6 Part code
27 . F5. A B U-9 0 0 A
Cooling
0, 5, A, F Heat sink (standard)
1, B, G Flat rear
2, C, H Water-cooling system
3, D, I Convection
Encoder interface
0:none
Switching frequency; short time current limit; overcurrent limit
0 2 kHz; 125 %; 150 % 5 4 kHz; 150 %; 180 % A 8 kHz; 180 %; 216 % F 16 kHz; 200 %; 240 %
1 4 kHz; 125 %; 150 % 6 8 kHz; 150 %; 180 % B 16 kHz; 180 %; 216 % G 2 kHz; 400 %; 480 %
2 8 kHz; 125 %; 150 % 7 16 kHz; 150 %; 180 % C 2 kHz; 200 %; 240 % H 4 kHz; 400 %; 480 %
3 16 kHz; 125 %; 150 % 8 2 kHz; 180 %; 216 % D 4 kHz; 200 %; 240 % I 8 kHz; 400 %; 480 %
4 2 kHz; 150 %; 180 % 9 4 kHz; 180 %; 216 % E 8 kHz; 200 %; 240 % K 16 kHz; 400 %; 480 %
Inputidentication
0 1ph 230 V AC/DC 5
400 V class DC A 6ph 400 V AC
1 3ph 230 V AC/DC 6 1ph 230 V AC B 3ph 600 V AC
2 1/3ph 230 V AC/DC 7 3ph 230 V AC C 6ph 600 V AC
3 3ph 400 V AC/DC 8
1/3ph 230 V AC D 600 V DC
4 230 V class DC 9 3ph 400 V AC
Housing type A, B, D, E, G, H, R, U, W, P
Internal options (A...D with STO relay according to EN954-1 / 1997)
0, A none
B Braking transistor without resistance monitoring
1, 5 Braking transistor with resistor monitoring
2, C integratedEMClter
3, D BrakingtransistorwithoutresistancemonitoringandEMClter
7 BrakingtransistorwithresistormonitoringandEMClter
Control type
A APPLICATION K like A with safety technology
C COMPACT (controlled frequency inverter)
E SCL P like E with safety technology
G GENERAL (controlled frequency inverter)
H ASCL L like H with safety technology
M
MULTI(regulated,eld-orientedfrequencyinverterforthree-phaseasynchronousmo-
tors)
S SERVO (regulated frequency inverter for synchronous motors)
Series F5/F6
Inverter size
