18
4.4. Right switch combination
①Flame out preset switch
②Electric start button
1、Flameout preset switch
The flameout switch is located on the right side of the direction handle, and the flameout preset switch has two positions：“ ”and“ ”。
The flameout switch is off-the ignition circuit is disconnected at this position, the running engine is turned off, and the
engine cannot be started.
The flameout switch is ON needs to be switched to this position during operation, and the ignition circuit is closed.
2. Electric start button
The method of operation is: After completing the preparations for starting (see page 16), press the electric start button“ ”，If necessary, turn the
throttle grip cover at the same time to refuel properly to start the engine.
Fig.6 Right switch combination
