Keithley 2110-100 Calibration Manual

Section
2: Adjustment Model 2110 5½ Digit Multimeter
Calibration Manual
2-4 2110-905-01 Rev. C / August 2013
ACV range adjustment
1. Set the Model 5700A to 0.01 V at 1 kHz and the output mode to STANDBY.
2. Using coaxial cable with dual banana terminals connect the Fluke 5700A output HI and LO to the
Model 2110 input HI and LO terminals. Allow connections to stabilize for a minimum of five
minutes before proceeding.
3. Configure the Model 2110 for the 0.1 V range by sending the following command:
CONF:VOLT:AC 0.1
4. Set the Model 5700A output mode to OPERATE.
5. Adjust to 10 percent of range by sending the following command:
CAL:PROT:AC:STEP 1,0.01
6. Wait until the following message is displayed on the Model 2110:
Cali OK
7. Set the Model 5700A output to 0.1 V.
8. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,0.1
9. Wait until the following message is displayed on the Model 2110:
Cali OK
10. Set the Model 5700A output mode to STANDBY.
11. Configure the Model 2110 for the 1 V range by sending the following command:
CONF:VOLT:AC 1
12. Set the Model 5700A to 0.1 V and the output mode to OPERATE.
13. Adjust to 10 percent of range by sending the following command:
CAL:PROT:AC:STEP 1,0.1
14. Wait until the following message is displayed on the Model 2110:
Cali OK
15. Set the Model 5700A output to 1 V.
16. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,1
17. Wait until the following message is displayed on the Model 2110:
Cali OK
18. Set the Model 5700A output mode to STANDBY.
19. Configure the Model 2110 for the 10 V range by sending the following command:
CONF:VOLT:AC 10
20. Set the Model 5700A to 1 V and the output mode to OPERATE.
21. Adjust to 10 percent of range by sending the following command:
CAL:PROT:AC:STEP 1,1
22. Wait until the following message is displayed on the Model 2110:
Cali OK
23. Set the Model 5700A output to 10 V.
24. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,10
25. Wait until the following message is displayed on the Model 2110:
Cali OK
