5½ Digit Multimeter Calibration Manual Section 2:
2110-905-01 Rev. C / August 2013 2-15
AC high current adjustment
1. Connect the Model 2110 3 A input jack to the 5725A 11A output (white to red on the Model
5725A and black of the Model 2110 to black of the Model 5725A). Configure the Model 5700 to
output current to the Model 5725A.
2. Configure the Model 2110 for the 3 A, 1 kHz current range by sending the following command:
CONF:CURR:AC 3
3. Set the Model 5700A to 0 A and the output mode to OPERATE.
4. Adjust front input offset by sending the following command:
CAL:PROT:AC:STEP 1,0
5. Wait until the following message is displayed on the Model 2110:
Cali OK
6. Set the Model 5700A output to 300 mA 1 kHz.
7. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,0.3
8. Wait until the following message is displayed on the Model 2110:
Cali OK
9. Set the Model 5700A output mode to STANDBY. .
10. Set the Model 5700A output to 3 A, 1 kHz.
11. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,3
12. Wait until the following message is displayed on the Model 2110:
Cali OK
13. Set the Model 5700A output mode to STANDBY.
14. Configure the Model 2110 for the 10 A DC current range by sending the following command:
CONF:CURR:AC 10
15. Set the Model 5700A to 1 A, 1 kHz and set the output mode to OPERATE.
16. Adjust front input offset by sending the following command:
CAL:PROT:AC:STEP 1,1
17. Wait until the following message is displayed on the Model 2110:
Cali OK
18. Set the Model 5700A output to 10 A, 1 kHz.
19. Adjust full scale measurement by sending the following command:
CAL:PROT:AC:STEP 2,10
20. Wait until the following message is displayed on the Model 2110:
Cali OK
