Keithley 2231A-30-3 User Manual

In this section:
Front-panel overview ................................................................ 2-1
Rear panel overview ................................................................. 2-2
Installing the system ................................................................. 2-2
Self-test procedure ................................................................... 2-6
Check the output ...................................................................... 2-7
What to do if the power supply does not turn on ....................... 2-8
Front-panel overview
The front panel of Model 2231A-30-3 is shown below. Descriptions of the controls on the front
panel follow the figure.
Figure 1: Model 2231A-30-3 front panel
Item Description
1 Vacuum fluorescent display (VFD)
2 Rotary knob
3 POWER button
4 Function buttons: Channel select buttons, V-Set (voltage setting), I-Set
(current setting), Menu and Output On/OFF
5 Numeric buttons and ESC button
6 Up/Down/Left/Right arrow buttons, Enter button and Save/Recall function
buttons
7 Output terminals
Section 2
Quick reference
