Model 2500 Service Manual Replaceable Parts 6-9
Table 6-2
Input board parts list
Circuit designation Description
Keithley
part no.
C327 CAP, .01UF, 10%, 200V, CERAMIC C-472-.01
C328,C337 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C329 CAP, 33PF, 10%, 100V, CERAMIC C-451-33P
C330 CAP, 10PF, 5%, 100V, CERAMIC C-372-10P
C333,C336,C338,C341 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C334,C335 CAP, .33U, 10%, 16V, TANTALUM C-585-3.3
C339,C340 CAP, 10UF, 20%, 25V, TANTALUM C-440-10
C342 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C345 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
CR305,CR306,CR307,CR308,CR309,
CR310
DIODE, SWITCHING, MMBD914 RF-83
J100 CONN, MALE 12 PIN RT ANGLE CS-612-12
J303 TRIAX RECEPTACLE, PCB MOUNT CS-995
K301 RELAY, 1FORMA, COTO 1203-0147 RL-181
K302,K303,K304,K305 RELAY, SURFACE MOUNT RL-188
Q301,Q302 TRANS, N-MOSFET, VN0605T TG-243
Q305,Q306 TRANS, N CHANNEL FET, 2N4392 TG-128-1
R300,R301,R302,R303 RES, 500, .1%, 1/10W, METAL FILM R-263-500
R308 RES, 50K, .1%, 1/10W, METAL FILM R-263-50K
R310,R315,R316 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R312 RES, 5M, 1%, 1W, METAL FILM R-502-5M
R313 RES, 500M, 1%, 1W, METAL FILM R-502-500M
R314,R305,R306,R311 RES, 392, 1%, 100MW, THICK FILM R-418-392
R317,R404,R406,R405 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R318,R323 RES, 24.9K, 1%, 100MW, THICK FILM R-418-24.9K
R319 RES, 71.5K, 1%, .1W, THIN FILM R-438-71.5K
R320 RES, 150, 1%, 100MV, THIN FILM 0805 R-438-150
R321 RES, 1.37K, 1%, .1W, THICK FILM R-418-1.37K
R407 RES, 100, 1%, 100MW, THICK FILM R-418-100
TP305,TP306 SURFACE MOUNT PCB TEST POINT CS-1026
U303,U304,U305 IC, CMOS ANALOG SWITCH IC-1395
U306 IC, 25 FEMTO-AMP ELECTRO AMP
LMC6001AIN
IC-1207
U307 IC, OP-AMP, NE5534D IC-802
VR301,VR302 DIODE, ZENER 10V, MMSZ5240B DZ-99
