System SourceMeter® Instrument Reference Manual Section 2:
2600BS-901-01 Rev. B / May 2013 2-5
8. Display indicators (not shown)
The items listed below represent the possible display indicators and their meanings.
Indicator Meaning
Instrument is in editing mode
Questionable reading or invalid calibration step
Instrument is in remote mode
Instrument is addressed to talk
Instrument is addressed to listen
Service request is asserted
Relative mode is enabled
Digital filter is enabled
Source or measure autorange is selected
Readings are being stored in the buffer
