System SourceMeter® Instrument Reference Manual Appendix E:
2600BS-901-01 Rev. B / May 2013 E-5
Status model diagrams
The following figures graphically describe the status model:
• Status byte and service request enable register (on page E-6)
• System summary and standard event registers (on page E-7)
• Measurement event registers (on page E-8)
• Operation status registers (on page E-9)
• Operation status trigger overrun registers (on page E-10)
• Operation status trigger timer, trigger blender, and remote registers (on page E-11)
• Operation status digital I/O and TSP-Link registers (on page E-12)
• Questionable status registers (on page E-13)
