B: Calibration Series 2600B System SourceMeter® Instrument
Reference Manual
B-24 2600BS-901-01 Rev. B / May 2013
Calibration commands quick reference
The following table summarizes remote calibration commands. For a more complete description of
these commands, refer to the TSP command reference (on page 7-1
).
Calibration commands
Command** Description
smuX.cal.adjustdate = adjustDate
Set date when the adjustment was done.
smuX.cal.date = calDate
Set calibration date (calDate of 0 indicates date not set).
smuX.cal.due = calDue
Set date when calibration should be performed (calDue of 0
indicates date not set).
smuX.cal.password = "newPassword"
Change password to "newPassword".
smuX.cal.polarity = calPolarity
Set polarity:
smuX.CAL_AUTO (automatic polarity).
smuX.CAL_NEGATIVE (negative polarity).
smu
X
.CAL_POSITIVE
(positive polarity).
smuX.cal.restore(calset)
Load set of calibration constants:
smuX.CALSET_NOMINAL (nominal constants).
smuX.CALSET_FACTORY (factory constants).
smuX.CALSET_DEFAULT (normal constants).
smu
X
.CALSET_PREVIOUS
(previous constants).
smuX.cal.save()
Store constants in nonvolatile memory as DEFAULT
calibration set.
calstate = smuX.cal.state
Request calibration state:
smuX.CALSTATE_CALIBRATING
smuX.CALSTATE_LOCKED
smu
X
.CALSTATE_UNLOCKED
smuX.cal.unlock("password")
Unlock calibration (default password: KI0026XX)
smuX.measure.calibratei(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
Adjust current measurement range calibration*:
±range (measurement range to adjust).
cp1Measured (Series 2600B measured value for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Measured (Series 2600B measured value for cal. point 2).
cp2Reference
(reference measurement for cal. point 2).
smuX.measure.calibratev(range,
cp1Measured, cp1Reference,
cp2Measured, cp2Reference)
Adjust voltage measurement range calibration*:
±range (measurement range to adjust).
cp1Measured (Series 2600B measured value for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Measured (Series 2600B measured value for cal. point 2).
cp2Reference (reference measurement for cal. point 2).
smuX.source.calibratei(range,
cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
Adjust current source range calibration*:
±range (source range to adjust).
cp1Expected (source value programmed for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Expected (source value programmed for cal. point 2).
cp2Reference
(reference measurement for cal. point 2).
smuX.source.calibratev(range,
cp1Expected, cp1Reference,
cp2Expected, cp2Reference)
Adjust voltage source range calibration*:
±range (source range to adjust).
cp1Expected (source value programmed for cal. point 1).
cp1Reference (reference measurement for cal. point 1).
cp2Expected (source value programmed for cal. point 2).
cp2Reference (reference measurement for cal. point 2)
